Datavideo PTC-140 NDIW
SKU: 7000-3067
This product is no longer offered. Please select from the alternatives below.
Top accessories for Datavideo PTC-140 NDIW
Datavideo WM-1 Black Wall Mount for PTZ Cameras
The Datavideo WM-1 is a three-piece wall-mount kit for fixed installation of compatible
139 €
To be sent 1 pcs
Datavideo BB-1 KIT dvCloud Remote Device Control Kit
Promotion: -30%
The BB-1 allows you to access almost to any IP enabled device over the public internet.
387.81 €
550.55 €
To be sent 1 pcs
Datavideo RMC-2P 3-Channel Camera Controller with Plate
The Datavideo RMC-2P is a three-channel controller for Datavideo PTZ cameras. Over
321 €
In stock 1 pcs
Datavideo iCAST 10NDI 5-Channel All-in-One Streaming Switcher
iCAST 10NDI is a new and innovative live production equipment that houses a switcher,
3 439 €
new product, yet unavailable
Lilliput K1 PTZ Camera Controller with Joystick
The Lilliput K1 is a professional PTZ camera controller with a joystick and an aluminium
499 €
14-30 days
Datavideo WM-1W White Wall Mount for PTZ Cameras
Datavideo WM-1W is the white version of the WM-1 wall mount for PTC-series PTZ cameras.
139 €
14-30 days
Datavideo IP68 PTZ Camera Housing (D2-BASE-EXT)
The Datavideo D2-BASE-EXT protective housing is compatible with PTC-140, PTC-145,
769 €
on request
Libec LX ePed
LX-ePed / LX-ePed Studio is Libec’s electronical pedestal system specially designed
2 709 €
on request
Datavideo iCAST Mini 4K Dual-Channel Presentation Switcher
Datavideo iCAST Mini is a compact 4K presentation switcher for corporate training,
2 199 €
14-30 days
Datavideo RMC-300A Universal PTZ Camera Control Panel
The Datavideo RMC-300A is a universal control panel for multi-camera PTZ and block-camera
1 679 €
14-30 days
Product description
ARTICLES
Product description
Add an HD camera with NDI streaming capability to your broadcast, house of worship, corporate, or education environment with this dark blue PTC-140NDI SDI/HDMI/NDI PTZ Camera with 20x Optical Zoom from Datavideo. The versatile PTZ supports frame rates and resolutions up to 1080p60 and features a 1/2.8" CMOS sensor with 2.07 MP resolution. The built-in zoom lens features an optical zoom range of 20x, and you can zoom in even further with the 10x digital zoom. It supports HDMI, SDI, and NDI|HX video output compatible with any standard NDI network or any video streaming platform such as YouTube, Skype, WebEx, Zoom, and many others.
With 255 programmable preset positions, you can set the camera to rapidly move to between positions using DVIP, RS-232 serial, or IR control, and it features a built-in tally light. The camera compresses using either or both the H.264 and H.265, as its onboard encoder is capable of encoding two streams at the same time. You can stream live using RTSP or RTMP protocols as well as stream video and control when on an NDI network using high-quality, low-latency HDI|HX technology. The camera supports external audio via a 3.5mm stereo line-level input as well as embedded audio using AAC, MP3, and G.711a compression formats.
The camera can be powered using the included power adapter or by using PoE (Power-over-Ethernet) to cut down on cabling within your environment.
Suitable for broadcast, worship, video conferencing, corporate, and education environments
Video streaming application support for services such as Skype, GoToMeeting, WebEx, Zoom, and YouTube
Output resolution up to 1920 x 1080p60 with a 2.07MP 1/2.8" CMOS sensor
20x optical zoom, 10x digital zoom; M52 lens filter thread with UV filter and can be removed for optional filters
Single-cable concept helps you to transfer video, audio, power, tally, and control over only one Ethernet cable via NDI|HX and PoE (Power-over-Ethernet)
Advanced 2D/3D noise reduction technology is used to further reduce the noise, ensuring image sharpness
Analog 3.5mm audio input interface; supports AAC, MP3, and PCM audio compression output
Supports compression of resolutions up to 1920 x 1080p60 and 2-channel 1920 x 1080p30
Multiple Network Protocols: RTSP, RTMP protocols and support, easy to link to a streaming media server
RS-232, RS-422, and RS-485 ports to use DVIP and VISCA commands to integrate with larger control systems
Tally lights show the preview and program status
Compatible with optional RMC-180, RMC-300C, and RMC-300A camera control units
ARTICLES
WE RECOMMEND
The Datavideo PTC-140 NDI W is a professional Full HD PTZ camera with support for NDI|HX, SDI, and HDMI outputs, ideal for streaming and multi-camera production. Key accessories for this model include signal management, network infrastructure, and integration into studio systems.
Signal Converters and Distribution - Devices for converting and extending the range of SDI and HDMI signals from the camera.
Production and IP Workflow - Systems for image processing and decoding IP streams from NDI cameras.
Audio and Communication - Accessories for audio synchronization and communication between operators.
Reading devices - Teleprompters suitable for integration with PTZ cameras in professional studios.
Installation and Monitoring - Accessories for secure camera mounting and previewing the final image.
Parameters
| Manufacturer: | Datavideo |
| Category: | PTZ |
Main parameters
| Resolution | Full HD |
| Type of bayonet | integrated lens |
| Output | HDMI · NDI · 3G SDI |
Other parameters
| Version | PTZ |
| FPS | HD 60fps |
| Lens lens aperture | 1.6f |
| Min. focal length | 5.2mm |
| Max. focal length | 98mm |
| Other features | PTZ · Streaming · PoE · NDI / NDI HX |
| Control protocol | NDI · RS-422 |
