RGBlink aura UHD studio 24 (Gen 2)

The RGBlink Aura UHD Studio 24 Gen 2 is a 23.8” professional 4K HDR broadcast-grade monitor designed for post-production and live production workflows. It features quad 12G-SDI monitoring, Thunderbolt™ connectivity for app previews, high-precision 3D LUT support, HDR waveform, ARRI/Red false color, and independent color modes per window.

The aura UHD studio 24 is a 23.8-inch 4K HDR monitor for broadcast, film and post-production. Its 3840 × 2160 LCD panel with 1000 cd/m² shows four 12G-SDI signals at once, Thunderbolt 3 brings in the DaVinci Resolve output and the 12G-SFP fiber port carries the picture over long distances.

A monitor for film and television production

Four 12G-SDI inputs accept up to 8K (quad link) and are backward compatible down to 4K60, joined by two HDMI inputs and USB-C with Thunderbolt 3. The monitor works with 3D LUTs using tetrahedral interpolation, SMPTE ST 2084 (PQ) and HLG HDR curves as well as camera Log curves, and it recognises the HDR transfer type on SDI and HDMI by itself.

Accurate colour with 3D LUTs

A high-precision 3D LUT with tetrahedral interpolation and the built-in Rainbow colour management engine keep colours accurate. Your own LUTs and gamma curves can be uploaded to the monitor, so the intended film look can be shown on set.

Wide colour gamut

The monitor covers 100 % of Rec.709 and 98 % of DCI-P3 and switches between ITU-R BT.2020, ITU-R BT.709, EBU, SMPTE-C and the native panel gamut – for broadcast and film alike.

Four cameras on one monitor

Quad view, quad view with three windows, PBP and PAP modes. Unlike the first generation, four 12G-SDI signals can be watched in four windows at the same time, each window has its own colour mode and audio bars, and SDR and HDR pictures can be compared side by side (HLG 1.0–1.5, ST 2084 PQ, S-Log3).

Inputs, outputs and fiber

Four 12G-SDI inputs with four loop-through outputs, two HDMI inputs, USB-C and a 12G-SFP port for single-mode fiber. The input signal can be up to 8K, and a single fiber cable carries 4K video together with audio.

Edit preview over Thunderbolt 3

The Thunderbolt 3 compatible USB-C port is used to preview the output of DaVinci Resolve or Adobe Premiere Pro – it does not mirror or extend the computer desktop. The monitor reads the Payload ID from the 12G-SDI signal automatically.

Tally, UMD and film looks

Three-colour tally, a dynamic UMD label over TSL 3.1/4.0/5.0 via RS-422, and 3D LUTs that show the film look on the monitor while you shoot.

Audio, mounting and scopes

The monitor de-embeds 16 audio channels from SDI and shows up to 8 of them on meters, and it has a built-in speaker and a 3.5 mm headphone jack. VESA mounting points are on the back. Tools include waveform with HDR, vectorscope, histogram, false colour with ARRI and RED profiles, peaking, zebra, time code, image flip, freeze and zoom.

More information

The RGBlink Aura UHD Studio 24 Gen 2 is a next-generation 23.8” UHD 4K HDR IPS monitor built for broadcast, film, and professional post-production workflows. The monitor delivers 3840 × 2160 resolution, 1000-nit brightness, and 98% DCI-P3 wide color gamut, providing precise and consistent color for critical production work. The 10-bit IPS panel supports HDR gamma curves including PQ, HLG, and S-Log3, as well as camera Log formats, with custom 3D LUT import using a tetrahedral interpolation algorithm for accurate color matching across multiple displays.

Compared to the first generation, the Studio 24 Gen 2 enables quad-view monitoring of four 12G-SDI signals simultaneously, with each window capable of selecting an independent color mode and displaying corresponding audio pillars. The monitor also supports HDR waveform analysis and false color with ARRI and Red camera profiles. A standout feature of the Studio series is direct app preview via Thunderbolt™, allowing live monitoring of outputs from DaVinci Resolve™ or Adobe Premiere Pro™. Additional professional features include DC 24V XLR power, V-mount battery support, and circuits optimized for energy efficiency, ESD, and EMI. With its combination of high brightness, color accuracy, and advanced workflow integration, the Aura UHD Studio 24 Gen 2 is ideal for film, TV, advertising, and post-production environments.

Key Features:

• 23.8” UHD 4K IPS LCD panel
• 1000-nit high brightness
• 98% DCI-P3 wide color gamut
• Quad 12G-SDI monitoring with independent color mode per window
• HDR waveform and false color support (ARRI & Red)
• Custom 3D LUT import (tetrahedral interpolation)
• Thunderbolt™ connectivity for preview of DaVinci Resolve™ and Adobe Premiere Pro™ outputs
• Audio pillars per window in quad-view
• DC 24V XLR power, V-mount battery compatible
• Energy-saving, ESD & EMI-optimized circuits
• Supports PQ, HLG, S-Log3, and camera Log gamma curves
