Datavideo RMC-260 Remote Control Panel for SE-1200MU Switcher

+2
SKU: 2205-1750

The Datavideo RMC-260 is a hardware control panel for the SE-1200MU Digital Video Switcher. Connected via RS-232, it provides a physical alternative to software control, with clearly labelled keys, two controls for the keyers, and user-memory keys for quickly recalling saved settings. It suits a production desk where operators need direct access to switching,…

More information

789 € with VAT 652.07 € without VAT
Add to Compare Price history
Availability
14-30 days
SKU:
2205-1750
Add to Compare Price history
Product description SPECIFICATIONS PACKAGE CONTENT

Product description

The Datavideo RMC-260 is a hardware control panel for the SE-1200MU Digital Video Switcher. Connected via RS-232, it provides a physical alternative to software control, with clearly labelled keys, two controls for the keyers, and user-memory keys for quickly recalling saved settings. It suits a production desk where operators need direct access to switching, transitions, keying, and still capture.

Datavideo RMC-260 – hardwarový ovládací panel

SE-1200MU CONTROL PANEL

The RMC-260 puts SE-1200MU switcher control on a dedicated physical panel. It communicates with the switcher over RS-232 and offers clearly labelled keys as an alternative to the software control panel.

Datavideo RMC-260 user-memory key detail

Saved settings

Store user behaviour and custom settings on the user-memory keys, then recall them quickly when needed.

Operator using the Datavideo RMC-260 during a live production

Direct hardware operation

The dedicated panel gives operators physical access to SE-1200MU control. Connected over RS-232, it keeps keying, switching, and other controls within easy reach during a live production.

Direct switching

XPT, Take, FTB, Cross Dissolve and Still Grab keys provide direct access to source assignment, PVW/PGM switching, transitions and still capture.

PACKAGE CONTENT

  • 1× Datavideo RMC-260 control panel
  • 1× AD Switch DC 12 V power adapter
  • 1× DB9P-to-DB9P cable
  • 1× Thank You card

SPECIFICATIONS

  • Type: hardware control panel for the SE-1200MU Digital Video Switcher
  • Communication interface: RS-232
  • Baud rate: 38,400, odd parity
  • Firmware update: USB
  • Power adapter: AC 100–240 V input; DC 12 V output
  • Panel power: DC 12 V / 0.5 A
  • Power consumption: 5 W
  • Operating temperature: 0–40 °C
  • Relative humidity: 10–90%, non-condensing
  • Dimensions (L × W × H): 430 × 261 × 70 mm
  • Net weight: 1.3 kg

WE RECOMMEND

The Datavideo RMC-260 is a hardware control console designed for efficient control of the SE-1200MU production switcher via an RS-232 interface. To create a fully-fledged production environment, it is recommended to supplement it with intercom systems, signal converters, and monitoring equipment from the same ecosystem.

Intercoms and Communication - Essential systems for communication between the control room and camera operators during live broadcasts.

Signal Converters - Devices for converting and distributing video signals between different formats within the production chain.

Audio and Sound Processing - Tools for synchronizing and mixing audio with video output from the control room.

Monitoring and streaming - Equipment for previewing the final image and its subsequent encoding for internet broadcasting.

Reading devices and accessories - Professional teleprompters and accessories for studio work with presenters.

Accessories and Mounting - Accessories for installing equipment in racks and protecting camera systems.

Parameters

Parameters

Manufacturer: Datavideo
Category: Control panels

Main parameters

InterfaceRS-232
