Teradek Bolt 6 LT MAX RX V-Mount

The Teradek Bolt 6 LT MAX RX V-Mount (10-2282-V) is a standalone wireless receiver designed for professional monitoring. It supports up to 4K30 via HDMI or 1080p60 10-bit 4:2:2 HDR via 3G-SDI and operates in the 5 GHz and 6 GHz bands with Zero-Delay technology.

More information

8 299 € with VAT 6 858.68 € without VAT
-+
Availability
on request
Product description SPECIFICATIONS PACKAGE CONTENT

Product description

The Teradek Bolt 6 LT MAX RX V-Mount (10-2282-V) is a standalone wireless receiver designed for professional monitoring. It supports up to 4K30 via HDMI or 1080p60 10-bit 4:2:2 HDR via 3G-SDI and operates in the 5 GHz and 6 GHz bands with Zero-Delay technology.

The MAX version offers the longest range in the Bolt 6 LT series: when using the optional Array antenna and Broadcast mode, it can be configured for up to 5,000 feet in line of sight. Up to 6 receivers can be connected to a single transmitter in normal mode; Broadcast mode on the MAX allows for an unlimited number of receivers. The integrated V-Mount plate is designed for a compatible V-Mount battery.

MAX RECEIVER FOR DEMANDING WIRELESS MONITORING

This standalone RX expands the Bolt system with HDMI and 3G-SDI outputs, V-Mount power, and Broadcast mode for more extensive distribution workflows.

PACKAGE CONTENT

  • Teradek Bolt 6 LT MAX RX V-Mount ×1

SPECIFICATIONS

  • SKU: 10-2282-V
  • Video: up to 4K30 via HDMI / up to 1080p60 10-bit 4:2:2 HDR via 3G-SDI
  • Outputs: HDMI 1.4b Type-A, 3G-SDI (BNC)
  • Bands: 5 GHz and 6 GHz
  • Power: 6–28 V DC, V-Mount
  • Power consumption: 9 W
  • Operating temperature: 0–40 °C
Parameters

Parameters

Manufacturer: Teradek
Category: Wireless video transmission
