Kinefinity EAGLE SDI e-Viewfinder (Black)

The Kinefinity EAGLE SDI e-Viewfinder Black (K110-001-01) is an ultralight 0.7" 1080p Micro-OLED EVF with 10-bit color, 10,000:1 contrast, zero-latency 3G-SDI, and full pro tools. Includes Mini Mount (360°), 15.7" D-Tap + BNC combo cable, -6 to +2 diopter—perfect for MAVO Edge, ARRI, RED.

The Kinefinity EAGLE SDI e-Viewfinder Black (K110-001-01) is a premium, ultra-compact electronic viewfinder in matte black finish. Its 0.7" 1920×1080 Micro-OLED panel delivers 1.07 billion colors (10-bit), 10,000:1 contrast, 33° FOV, and zero-delay monitoring via 3G/HD-SDI (up to 1080p60). Advanced tools include waveform, RGB parade, histogram, false color, zebra, peaking, anamorphic de-squeeze, frame markers, and flip/rotate. The adjustable diopter (-6 to +2) works flawlessly with glasses. Included Mini Mount attaches via 1/4"-20 or ARRI rosette with 360° rotation and quick-lock. The bundled 15.7" sheathed combo cable supplies power (right-angle D-Tap) and video (right-angle BNC) in one tidy run from V-mount batteries. At only 348 g with full aluminum/steel/glass construction and 5 W draw, it’s the lightest, most feature-rich SDI EVF for Kinefinity MAVO Edge, ARRI Alexa Mini/LF, RED Komodo/V-Raptor, and any 3G-SDI camera.

Key Features:

• 0.7" Full HD Micro-OLED, 10-bit, 10,000:1 contrast, 1.07B colors
• Zero-latency 3G/HD-SDI (1080p60/59.94/50, PsF, 1080i)
• Full toolset: waveform, histogram, false color, peaking, anamorphic de-squeeze
• Diopter -6 to +2, 33° FOV, eyecup with proximity sensor
• Included Mini Mount with 360° rotation + ARRI rosette
• 15.7" right-angle D-Tap + BNC sheathed combo cable
• Matte black finish, 5 W power
