Kinefinity MAVO mark2 LF (E Mount)

The Kinefinity MAVO mark2 LF E-Mount (A010-003-03) is a full-frame 6K cinema camera with 3:2 CMOS, dual native ISO 800/5120, 86 fps at 6K Wide, ProRes 4444XQ, and native Sony E-mount. Ultra-compact 1.37 kg body, active PL/E adapters, full-frame anamorphic de-squeeze, KineLOG3—perfect for cinematic handheld and gimbal work.

More information

7 989 € with VAT 6 602.48 € without VAT
-+
Availability
on request
Product description SPECIFICATIONS PACKAGE CONTENT

Product description

The Kinefinity MAVO mark2 LF E-Mount (A010-003-03) is a full-frame 6K cinema camera with 3:2 CMOS, dual native ISO 800/5120, 86 fps at 6K Wide, ProRes 4444XQ, and native Sony E-mount. Ultra-compact 1.37 kg body, active PL/E adapters, full-frame anamorphic de-squeeze, KineLOG3—perfect for cinematic handheld and gimbal work.

The Kinefinity MAVO mark2 6K LF E-Mount (A010-003-03) combines the same 24 MP full-frame 3:2 CMOS sensor as the MAVO Edge 6K with next-gen processing for 14+ stops, cleaner shadows, and superior highlight roll-off. It delivers 6K Wide up to 86 fps or 4K 112 fps in ProRes 4444XQ, with in-camera de-squeeze for full-frame anamorphic (4:3 5120×3700 or 6:5 4608×3700). The 1.37 kg aluminum body features dual proprietary video outputs, 3G-SDI, 2x XLR audio, timecode, sync, and hybrid V-mount/BP-U plate. Record to KineMAG Nano SSDs with ProRes 422–4444XQ and compressed cDNG (3:1/5:1/7:1). Wi-Fi control via Kinefinity app, KineLOG3 gamma, and full TERRA accessory compatibility make it the ultimate compact full-frame cinema tool for films, commercials and high-end documentary.

Key Features:

  • Full-frame 6K 3:2 CMOS (6016×3984), 14+ stops, dual native ISO 800/5120
  • 6K86 Wide ProRes 4444XQ, 4K112, full-frame anamorphic de-squeeze
  • Native Sony E-mount + active PL/E adapters with lens control & metadata
  • KineLOG3, custom 3D LUTs, compressed cDNG (Resolve-ready)
  • Dual proprietary video, 3G-SDI, 2x XLR, timecode, sync
  • KineMAG Nano SSD (1 TB/2 TB or third-party NVMe)
  • Wi-Fi 5 app control, 23 W power, V-mount/BP-U hybrid
  • Ultra-light 1.37 kg with optical LPF + UV/IR cut

PACKAGE CONTENT

  • Kinefinity MAVO mark2 6K LF Digital Cinema Camera (Sony E)
  • KineMOUNT Lens Mount
  • Body Cap

SPECIFICATIONS

  • Model: MAVO mark2 6K LF E-Mount (A010-003-03)
  • Sensor: Full-frame 3:2 CMOS, 24 MP (6016×3984)
  • Lens Mount: Sony E (native); active PL, KineMOUNT + EF/LPL adapters (separate)
  • ISO: Dual native 800 & 5120 (extended 800–5120)
  • Dynamic Range: 14+ stops
  • Recording Formats:
    • ProRes 422 LT/HQ/Proxy, 4444/4444XQ (10/12-bit)
    • cDNG compressed (3:1, 5:1, 7:1)
  • Frame Rates:
    • 6K Open Gate 48 fps
    • 6K Wide 86 fps
    • 4K Wide 112 fps
    • Anamorphic: 5.1K 4:3 50 fps, 4.6K 6:5 60 fps
  • Video Outputs: 2x proprietary, 1x BNC 3G-SDI
  • Audio: 2x XLR mic/line (+48 V), 3.5 mm mic/headphone; 24-bit/48 kHz LPCM
  • Media: 1x KineMAG Nano (NVMe M.2 2280)
  • Power: 11–19 V DC, 23 W; V-mount or BP-U plate
  • Connectivity: Wi-Fi 5, USB-C, RS-232, timecode, RS-422 sync
  • Dimensions: 124 × 107 × 106 mm
  • Weight: 1.37 kg (body only)
  • Operating Temp: 0–40 °C
Parameters

Parameters

Manufacturer: Kinefinity
Category: Compact cameras

Main parameters

Camera Sensor sizeFull-frame 3:2 CMOS
Resolution24 MP (6016×3984)
Type of bayonetMAVO mark2
OutputNVMe M.2 2280

Other parameters

FPS5.1K 4:3 50 fps, 4.6K 6:5 60 fps
Media type1x KineMAG Nano
Battery type11–19 V DC (LEMO), 23 W; V-mount or BP-U battery plate
Other featuresWiFi
Native ISO999999999.9
