Kinefinity EAGLE SDI e-Viewfinder (Cyber)

The Kinefinity K110-001-02 EAGLE SDI e-Viewfinder (Cyber) is a premium, zero-latency 1080p micro-OLED EVF in striking silver, featuring 3G/HD-SDI input, 10-bit color, 10,000:1 contrast, pro tools (waveform, vectorscope, false color, peaking, de-squeeze), -6 to +2 diopter, run/stop trigger, and D-Tap power—delivering ARRI-grade monitoring in a 348 g aluminum body for MAVO Edge, RED, ARRI, and all SDI cinema cameras.

The Kinefinity EAGLE SDI e-Viewfinder (Cyber Edition) is a flagship electronic viewfinder that fuses cutting-edge micro-OLED technology with cine-grade connectivity. Its 0.7" 1920×1080 display delivers 10,000:1 contrast, 1.07 billion colors (10-bit), and 100% DCI-P3 coverage with zero perceptible latency via 3G/HD-SDI input (up to 1080p60). Full KineOS-style tools include waveform, vectorscope, histogram, RGB parade, false color, zebras, focus peaking, anamorphic de-squeeze (0.75–2.0×), frame markers, and image flip/rotate. A 5-pin LEMO accepts 6–28 V power (D-Tap cable included), with run/stop trigger support. The diopter adjusts from -6 to +2, and an ARRI rosette + 1/4"-20 thread on the right side enables rock-solid mounting. Housed in aluminum with a cyber silver finish, it weighs just 348 g and firmware-updates via USB-C. Perfect for DPs who demand precision monitoring on MAVO Edge, ALEXA Mini, or any SDI-equipped camera.

Key features

• 0.7" 1080p micro-OLED (10,000:1, 10-bit, 100% DCI-P3)
• Zero-latency 3G/HD-SDI input (1080p60, 1080i60)
• Full pro tools: waveform, vectorscope, false color, peaking, de-squeeze
• Diopter –6 to +2 (glasses-friendly)
• Run/stop trigger + D-Tap power (6–28 V)
• ARRI rosette + 1/4"-20 mount (right side)
• 5 programmable function buttons
• USB-C firmware update
• Cyber silver aluminum body (348 g)
