Exascend Industrial Cfexpress CFB400 PCIe Gen4 1TB

The Exascend Industrial CFexpress CFB400 PCIe Gen4 1TB (EXPC4SB001TB-I) is a rugged CFexpress Type B card with 176-layer 3D TLC NAND, offering up to 3,500 MB/s read and 3,000 MB/s write speeds for high-bandwidth 8K/4K video and bursts. Operating from -40°C to +85°C with Adaptive Thermal Control, SED encryption (TCG Opal 2.0), 370k/170k IOPS,  it's ideal for industrial cameras, surveillance, and embedded systems.

The Exascend Industrial CFexpress CFB400 PCIe Gen4 1TB (Part # EXPC4SB001TB-I) is a high-performance, ultra-reliable CFexpress Type B memory card engineered for extreme professional and industrial applications, such as 8K RAW video recording, machine vision, and rugged surveillance systems. Featuring 176-layer 3D TLC NAND flash managed by a PCIe Gen 4x2 interface (up to 32 GT/s bandwidth), it achieves sequential read speeds up to 3,500 MB/s and write speeds up to 3,000 MB/s, alongside 370,000 IOPS for 4K random read and 170,000 IOPS for random write ensuring buffer-free performance in high-throughput workflows. Built for harsh conditions, it operates from -40°C to +85°C (storage -45°C to +90°C) with 5–95% humidity tolerance, low power consumption (active <4.5 W, idle <0.8 W at 3.3 V ±5%), and rugged durability: vibration-resistant to 10 G (10–2,000 Hz), operating shock 50 G (11 ms half-sine), non-operating shock 1,500 G (0.5 ms), and MTBF of 2,000,000 hours. The compact CFexpress Type B form factor (38.0 x 29.8 x 3.8 mm) fits seamlessly into cinema cameras, drones, and embedded PCs, supporting PCIe Gen 4x2 for future-proof compatibility.

Key Features

• PCIe Gen 4x2: Up to 3,500 MB/s read, 3,000 MB/s write for 8K/4K workflows
• 176-layer 3D TLC NAND: High-density endurance with 370k/170k IOPS
• Adaptive Thermal Control: Dynamic power management prevents overheating
• SED encryption: TCG Opal 2.0 hardware security for sensitive data
• Extreme durability: -40°C to +85°C, 10 G vibration, 1,500 G shock, IPX7 waterproof
• Low power: 3.3 V, <4.5 W active for embedded/rugged systems
