RGBlink single-mode SFP-20KM

SKU: 950-0008-00-0

The RGBlink single-mode SFP+ optical module carries 10.3 Gb/s at 1310 nm up to 20 km. It is intended for the RGBlink MSP 217 3G-SDI fibre converter. The 20 km module has the longest reach of the single-mode modules in the range – it links distant buildings, a stadium or an OB van far from the control room.

More information

130 € with VAT 107.44 € without VAT
Add to Compare Price history
Availability
on request
SKU:
950-0008-00-0
Add to Compare Price history

RGBlink multi-mode SFP

77 €without VAT 63.64 €

RGBlink single-mode SFP-2KM

99 €without VAT 81.82 €
Product description SPECIFICATIONS PACKAGE CONTENT

Product description

The RGBlink single-mode SFP+ optical module carries 10.3 Gb/s at 1310 nm up to 20 km. It is intended for the RGBlink MSP 217 3G-SDI fibre converter. The 20 km module has the longest reach of the single-mode modules in the range – it links distant buildings, a stadium or an OB van far from the control room.

For shorter runs the same range offers the SFP-2KM and SFP-10KM modules.

Key features

  • 10.3 Gb/s over single-mode fibre up to 20 km
  • 1310 nm wavelength
  • Twin-core cable with LC connectors
  • Hot-pluggable
  • For RGBlink MSP 217

PACKAGE CONTENT

  • SFP+ optical module for single-mode fibre – 1×

SPECIFICATIONS

  • Fibre: single-mode, twin-core
  • Fibre connector: LC
  • Wavelength: 1310 nm
  • Transmission rate: 10.3 Gb/s
  • Transmission distance: up to 20 km
  • TX power: −3 to +2.0 dBm
  • RX sensitivity: ≤ −14.4 dBm
  • Hot-plug: yes
  • For use with: RGBlink MSP 217
  • Order code: 950-0008-00-0

WE RECOMMEND

The RGBlink Single-mode SFP-20KM is a high-performance optical module designed for stable data transmission over distances of up to 20 km using single-mode fiber. It is an ideal addition to RGBlink MSP series devices, professional production consoles, and PTZ cameras equipped with an SFP slot for remote signal distribution.

Signal Processing and Control Rooms - MSP series devices and advanced control rooms are directly compatible with SFP modules for optical transmission.

PTZ Cameras - Professional cameras with support for remote control and video transmission that can be integrated into optical networks.

Accessories and Mounting - Accessories for installing camera systems using optical connections.
