Blackmagic Design Teranex Mini SDI to HDMI 8K HDR – used - unpacked, full warranty

• 1× Teranex Mini SDI to HDMI 8K HDR
• 1× welcome card with a QR code for software download

The package contents correspond to a new unit as specified by the manufacturer. For used items, the actual range of accessories may vary—please verify this before ordering.

• SDI Inputs: 4× 12G‑SDI with automatic HD/2K/4K/8K switching; dual-link and quad-link 12G‑SDI for 8K only
• SDI Outputs: 4× 12G-SDI loop-through outputs
• HDMI Outputs: 4× HDMI 2.0 Type A — HD, Ultra HD, and 4K in single-link mode; 4320p60 in quad-link mode
• Analog audio output: 2 channels via RCA connectors
• Embedded audio: 16 channels on SDI outputs, 8 channels on HDMI outputs
• Supported data rates: 1.5G, 3G, 6G, 12G, 2SI dual-link 12G-SDI, 2SI quad-link 12G-SDI, Square Division quad-link 12G-SDI
• Reclocking: Yes
• HD standards: 720p50–60, 1080i50–60, 1080p23.98–60, 1080PsF23.98–30
• 2K DCI standards: 2Kp23.98–60 and 2KPsF23.98–30
• Ultra HD standards: 2160p23.98 to 2160p60
• 4K DCI standards: 4Kp23.98 to 4Kp60
• 8K standards: 4320p23.98 to 4320p60 and 8K DCI 8Kp23.98 to 8Kp60, automatic switching between 2SI and Square Division
• SDI Sampling: 4:2:2 and 4:4:4, YUV and RGB color spaces
• Audio sampling: 48 kHz, 24 bits
• HDMI color space: REC 709 and REC 2020
• HDMI color accuracy: YUV 4:2:2 in HD, 2K, 4K, and 8K; 33-point LUT via Teranex Utility or calibration LUT from a measurement probe
• Oscilloscopes: waveform, RGB/YUV parade, vectorscope, histogram — two side-by-side with image overlay and transparency control
• Controls: 6 buttons and a rotary knob, 2.2" color LCD display
• Updates and configuration: USB-C or Ethernet
• Power: built-in universal AC power supply, IEC C14 input, 100–240 V AC (power cord required)
• Power consumption: 25 W
• SDI Compliance: SMPTE 259M, 292M, 296M, 372M, 424M, 425M Levels A and B, 2081-1, 2081-10, 2082-1, 2082-10
• Operating temperature: 0 to 40 °C
• Storage temperature: −20 to 60 °C
• Relative humidity: 0 to 90%, non-condensing
• Manufacturer’s catalog number: CONVN8TRM/AA/SDIH
• Condition: used (secondhand)
