Teradek Bolt 6 LT 1500 TX

The Teradek Bolt 6 LT 1500 3G-SDI/HDMI Wireless Transmitter delivers visually lossless, low-latency wireless video transmission up to 1500' / 457 m line-of-sight. Supporting the new 6 GHz band, UHD 4K30 video, 10-bit HDR, HDMI and 3G-SDI inputs, and transmission to up to six receivers, it is designed for professional camera and monitor workflows.

The Teradek Bolt 6 LT 1500 3G-SDI/HDMI Wireless Transmitter provides reliable, low-latency wireless video transmission for professional production environments. It supports UHD 4K30 video, 10-bit 4:2:2 HDR, and HDMI or 3G-SDI input, with a 3G-SDI loop output for connecting additional equipment. Using the new 6 GHz wireless band, the transmitter can deliver video up to 1500' / 457.2 m line-of-sight, while maintaining compatibility with Bolt 4K series devices over the 5 GHz spectrum.

The Bolt 6 LT 1500 can transmit to up to six compatible Bolt receivers and features AES-256 encryption to help secure wireless video. Its compact aluminum and polycarbonate chassis includes an OLED status display, two RP-SMA antenna connections, interchangeable battery mounting, and 1/4"-20 mounting. Bluetooth connectivity enables wireless configuration through the Teradek app for iOS and Android, including spectrum analysis, channel selection, and remote configuration. The system also supports timecode and camera start/stop triggers, making it well suited to professional monitoring, live production, cinema, and camera-rig applications.

Key Features

• Supports the new 6 GHz wireless frequency band
• Wireless transmission range up to 1500' / 457.2 m line-of-sight
• Supports UHD 4K30 video transmission
• 3G-SDI and HDMI video inputs
• 3G-SDI loop output
• Supports 10-bit 4:2:2 HDR / Rec. 2020
• Transmits to up to 6 Bolt receivers
• Compatible with Bolt 6 series over 6 GHz
• Cross-compatible with Bolt 4K, Bolt 4K LT, and Bolt 4K Monitor Module devices over 5 GHz
• Less than 1 ms latency
• AES-256 encryption
• Improved long-range mode and noise rejection
• Built-in SDI Eye Pattern Tool
• Bluetooth connectivity for iOS/Android app control
• Spectrum analyzer and remote configuration
• Supports timecode and camera start/stop triggers
• Compact and lightweight chassis
• OLED status display
• Interchangeable battery mount; battery plate not included
