Teradek Bolt 6 LT 750 Int Ant TX

Bolt 6 LT 750 TX with Internal Antenna

Integrated antennas streamline and reinforce the camera setup while maintaining Bolt 6’s zero-latency transmission.

The Teradek Bolt 6 LT 750 transmitter with an internal antenna provides reliable, low-latency wireless video transmission for professional film, television, and production environments. With all antennas integrated into the housing, the transmitter features a clean, compact design while offering a line-of-sight wireless range of up to 750 ft / 228.6 m. When paired with compatible Bolt 6 receivers, it supports the 6 GHz frequency band and can also transmit visually lossless video to Bolt 4K series receivers in the 5 GHz band.

The transmitter accepts video via HDMI and 3G-SDI interfaces and features an SDI loop-through output for monitoring or signal distribution. The HDMI interface supports video up to UHD 4K30 resolution, while SDI supports up to 1080p60. The system supports 10-bit 4:2:2 video and Rec. 2020 HDR, which helps maintain image quality even in demanding production applications. Uncompressed wireless video transmission, extremely low latency of less than 0.01 ms, and support for 2-channel 24-bit/48 kHz audio provide a high-quality monitoring solution.

The Bolt 6 LT 750 transmitter can simultaneously transmit to up to six compatible receivers and is equipped with AES-256 encryption to help protect wireless video signals. Enhanced noise suppression and long-range mode help maintain reliable performance in busy RF environments. Support for timecode and camera trigger/stop further integrates the transmitter into professional camera workflows.

The built-in OLED/LCD display provides clear status information, while Bluetooth connectivity enables control via the Teradek Bolt app for iOS and Android. The app offers spectrum analysis, channel selection, and remote configuration options. The transmitter features 1/4"-20 and M3 mounting options for installation on cameras, cages, and production stands.

Key Features

• Wireless video transmitter with integrated internal antennas
• Line-of-sight transmission range up to 750 ft / 228.6 m
• Supports 6 GHz wireless connectivity
• Compatible with Bolt 6 receivers in the 6 GHz band
• Cross-compatible with Bolt 4K receivers in the 5 GHz band
• HDMI and 3G-SDI video inputs
• 3G-SDI loop-through output
• Supports up to UHD 4K30 via HDMI
• Supports resolutions up to 1080p60 via SDI
• Supports 10-bit 4:2:2 HDR
• Support for HDR according to Rec. 2020
• Uncompressed wireless video transmission
• Reported latency of less than 0.01 ms
• Simultaneous transmission to up to six receivers
• AES-256 encryption
• Enhanced noise reduction and long-range mode
• Timecode support
• Support for starting and stopping the camera
• Bluetooth connectivity
• Teradek Bolt app for iOS and Android
• Built-in spectral analyzer and remote configuration
• Compact aluminum construction
• Internal antennas for a clean and sleek design
• Mounting options for cameras, cage housings, and rigs
