SmallHD Ultra 10 Bolt 6 RX 750 Gold Mount Kit

The SmallHD Ultra 10 Bolt 6 RX 750 ft Gold Mount Kit is a premium 10-inch ultra-bright on-camera monitor with an integrated Teradek Bolt 6 receiver, delivering zero-delay wireless video monitoring up to 750 ft. Featuring 2000-nit brightness, 6G-SDI architecture, IP54-rated durability, and advanced PageOS control, it is designed for demanding professional film and broadcast environments requiring reliability, portability, and precision monitoring.

The SmallHD Ultra 10 Bolt 6 RX 750 ft Gold Mount Kit is a high-performance professional field monitor designed to combine ultra-bright display technology with integrated wireless video reception. Built for modern production workflows, it features a built-in Teradek Bolt 6 receiver, allowing zero-latency wireless video monitoring from compatible transmitters at distances up to 750 feet, making it ideal for on-set directors, focus pullers, and video assist teams.

At its core, the Ultra 10 features a 10.1-inch IPS LCD panel with 1920×1200 resolution and 2000 nits of brightness, ensuring excellent visibility even in bright daylight conditions. The monitor supports 10-bit processing, wide-format input compatibility, and 6G-SDI architecture for high-quality professional signal handling. It includes HDMI and SDI I/O with extensive format support across HD, 3G, 6G, and 4K workflows.

Designed for harsh production environments, the Ultra 10 is IP54 certified, offering resistance to dust, dirt, and water spray from any direction. Its rugged chassis includes reinforced edges, shock-absorbing, user-replaceable bumpers, and an operating temperature range of 0°C to 40°C, making it suitable for demanding field conditions.

Workflow control is powered by SmallHD’s PageOS platform, offering flexible navigation via touchscreen, joystick, tactile buttons, and rotary encoder knobs. Advanced monitoring tools include waveform, vectorscope, histogram, false color, focus assist, peaking, LUT support, image capture, multi-view, and customizable overlays. It also supports camera control integration (via optional licenses and cables) for systems such as ARRI, Sony VENICE, BURANO, FX6, and RED cameras.

Power flexibility is provided through Gold Mount or V-Mount battery plate options, along with a 2-pin locking DC input for extended production setups.

Key Features:

• 10.1” ultra-bright 2000-nit IPS display
• Integrated Teradek Bolt 6 RX with up to 750 ft wireless range
• 1920×1200 resolution with 10-bit processing
• 6G-SDI architecture with HDMI + SDI I/O support
• IP54-rated rugged, weather-resistant design
• PageOS workflow with touchscreen, joystick, and rotary encoder control
• Advanced monitoring tools (waveform, vectorscope, false color, LUTs, peaking, etc.)
• Multi-camera view and image capture capabilities
• Camera control support for ARRI, Sony, and RED (optional license)
• Gold Mount battery system compatibility
• Reinforced chassis with shock-absorbing bumpers
