SmallHD Ultra 10 Bolt 6 RX 1500 Gold Mount Kit

The SmallHD Ultra 10 Bolt 6 RX 1500 ft Gold Mount Kit is a premium 10-inch ultra-bright field monitor with an integrated Teradek Bolt 6 receiver, delivering zero-latency wireless video monitoring up to 1500 ft. Featuring 2000 nits brightness, 6G-SDI architecture, IP54-rated rugged construction, and advanced PageOS control, it is built for demanding professional cinema and broadcast production workflows.

The SmallHD Ultra 10 Bolt 6 RX 1500 ft Gold Mount Kit is a high-end professional on-set monitor designed for filmmakers who require maximum reliability, brightness, and wireless range in challenging production environments. Equipped with an integrated Teradek Bolt 6 receiver, it enables zero-delay wireless video transmission from compatible cameras at distances of up to 1500 feet, making it ideal for large-scale film sets, live productions, and remote monitoring workflows.

At its core, the Ultra 10 features a 10.1-inch IPS LCD panel with 1920×1200 resolution and an extremely bright 2000-nit backlight, ensuring excellent visibility even under direct sunlight. The monitor supports 10-bit processing, wide color accuracy, and extensive signal compatibility across SDI (HD/3G/6G) and HDMI formats, including up to 4K UHD input support. Its 6G-SDI architecture ensures robust professional signal handling for modern cinema pipelines.

Built for extreme environments, the Ultra 10 is IP54-certified, offering resistance to dust, dirt, and water spray while operating between 0°C and 40°C. The rugged chassis includes reinforced edges and user-replaceable shock-absorbing bumpers to protect against drops and impacts, making it suitable for demanding field use.

The monitor runs on SmallHD’s powerful PageOS platform, offering intuitive touchscreen control combined with physical joysticks, buttons, and rotary encoder knobs for precise operation in any condition. It includes advanced tools such as waveform, vectorscope, histogram, false color, focus assist, peaking, LUT support, image capture, multi-view, and extensive overlay customization for professional image analysis.

It also supports optional camera control integration for systems such as ARRI, Sony VENICE, BURANO, FX6, and RED cameras via Ethernet and USB accessories (licenses and cables sold separately). Power is provided through Gold Mount battery compatibility or DC input, offering flexibility across different production setups.

Key Features:

• 10.1” ultra-bright 2000-nit IPS display
• Integrated Teradek Bolt 6 receiver (up to 1500 ft range)
• 1920×1200 resolution with 10-bit processing
• 6G-SDI and HDMI input/output support (up to 4K UHD)
• IP54-rated rugged, weather-resistant chassis
• PageOS workflow with touchscreen, joystick, and rotary controls
• Advanced monitoring tools (waveform, vectorscope, LUTs, false color, peaking, etc.)
• Multi-view and image capture functionality
• Optional camera control support (ARRI, Sony, RED systems)
• Gold Mount battery compatibility with professional DC input options
• Shock-absorbing, field-replaceable protective bumpers
