Lilliput UQ31

The Lilliput UQ31 is a 31.5" 4K 1000-nit studio/production monitor with 8K-ready 12G-SDI ×4 (Quad-Link), 12G-SFP+, and HDMI 2.1 in/loop-out. Features Quad-View, 3D-LUT, HDR (HLG/ST2084 10000), waveform, vectorscope, and rugged flight-case—perfect for broadcast, color grading, and multi-cam live production.

The Lilliput UQ31 is a professional 31.5-inch 4K HDR reference monitor engineered for high-end studio, OB van, and on-set color-critical workflows. Its 3840×2160 10-bit IPS panel delivers 1000 cd/m² brightness, 1000:1 contrast, 178° viewing angles, and full support for Rec.709, DCI-P3, BT.2020, plus HDR HLG/ST2084 (300/1000/10000 nits). 8K-ready connectivity: 4× 12G-SDI (Quad-Link 8K 60p), 1× 12G-SFP+ fiber input, and 1× HDMI 2.1 (8K 60p single-cable) with loop-through ensure future-proof signal handling from ARRI, RED, Sony Venice, or Blackmagic URSA. Quad-View mode displays four independent 12G-SDI/HDMI sources simultaneously with individual LUTs, audio meters, and Tally. Advanced tools include waveform, vectorscope, histogram, false color, zebra, focus peaking, 3D-LUT (.cube) import via USB, and hardware calibration. Remote control via RS422, GPI, or LAN (RJ45) integrates seamlessly into broadcast ecosystems. Housed in a rugged aluminum alloy chassis with VESA 200×200/400×400 mounts and supplied in a portable flight-case, the 12.5 kg UQ31 operates on 15–32 V DC (XLR 4-pin) and consumes ≤94 W. Ideal for directors, DITs, colorists, and live-production teams demanding pixel-perfect accuracy and multi-signal flexibility.

Key Features:

• 31.5" 4K 10-bit IPS, 1000 nits, 178°/178°, 1000:1 contrast
• 8K inputs: 4× 12G-SDI (Quad-Link), 12G-SFP+, HDMI 2.1 (8K60 single-cable)
• Quad-View with independent LUTs, audio, and Tally per source
• HDR: HLG / PQ ST2084 300/1000/10000 + all major log formats
• Full toolset: waveform, vectorscope, histogram, false color, 3D-LUT import
• Remote: RS422 in/out, GPI, LAN (web GUI)
• Hardware calibration + audio vector, 16-ch SDI / 8-ch HDMI embedded
• Rugged flight-case included, VESA 200/400, 15–32 V XLR power
