Libec TH-X H

TH-X H is a video head with great diversity. Originally sold as part of the new TH-X tripod kit, the fluid head is now available separately as well! It can be attached on 65mm bowl tripods, monopods, sliders, skater dollies, or any system with a 3/8” screw on a flat base. The TH-X H camera attachment is diverse as well, you can conveniently use Manfrotto or Sachtler slide plates on this head without having to remove the slide plate from your camera.

The Libec TH-X H is a compact fluid head for cameras up to 4 kg, also supplied by the maker as part of the TH-X and TH-X2 systems. Its dual base fits tripods with a 65 mm bowl as well as the flat bases of sliders and photo tripods. The head weighs 1 kg and the bowl clamp is included.

A light fluid head up to 4 kg

Dual 65 mm ball / flat base, sliding plate compatible with Manfrotto and Sachtler, tilt +90° to −80°.

4 kg payloadWeight 1 kg65 mm ballFlat base±30 mm plateDual serrations

For photo and video

The head carries up to 4 kg: a DSLR, a mirrorless camera with a microphone or a small camcorder. Fixed counterbalance and drag need no fine-tuning.

An arm instead of a second handle

Serrations on both sides take a pan handle on the right, the left or both. The free side can hold the AS-7K arm for a monitor.

A handle for smooth moves

The long pan handle with a rubber grip gives calm pans and tilts. The bowl clamp is included.

One head, many supports

Thanks to the dual base, the TH-X H goes on a 65 mm bowl tripod as well as on a slider, a skater dolly or a photo tripod with a 3/8" screw. The plate attaches in one touch.

Tilt +90° to −80°

The head works from −20 to +60 °C.

Sliding plate

±30 mm balance travel, compatible with Manfrotto and Sachtler.

Bubble level

A level on the head speeds up setup.

Video pin

The plate holds the camera with a 1/4" screw and an anti-twist pin.

One-touch sliding plate. The plate attaches and releases in one touch and follows the standard used by other Libec supports as well as Manfrotto and Sachtler heads.

Dual base. The head sits on a 65 mm bowl and on a flat base alike, so it works on many different supports.

TH-X H counterbalance chart. The chart shows which camera weight the head balances depending on the height of the centre of gravity above the plate.
