| Lens mount |
FUJIFILM X bayonet |
| Image sensor |
23.5 mm x 15.6 mm (APS-C) X-Trans CMOS 4 with primary colour filter |
| Effective pixel count |
26.1 million pixels |
| Sensor cleaning system |
Ultra Sonic Vibration |
| Image processing engine |
X-Processor 4 |
| Storage media |
SD card (-2 GB) SDHC card (-32 GB) SDXC card (-2TB) UHS-I
*Please check the Fujifilm website for memory card compatibility. |
| Still image file format |
DCF: In accordance with the camera file system design rules (DCF2.0) JPEG: Exif Ver.2.32 RAW: 14-bit RAW (original RAF format)
*Exif 2.32 is a digital camera file format that contains a variety of capture information for optimal printing |
| Number of pixels recorded |
L: (3:2) 6240 x 4160 / (16:9) 6240 x 3512 / (1:1) 4160 x 4160 M: (3:2) 4416 x 2944 / (16:9) 4416 x 2488 / (1:1) 2944 x 2944 S: (3:2) 3120 x 2080 / (16:9) 3120 x 1760 / (1:1) 2080 x 2080 |
| Panorama |
L: (vertical) 9600 x 2160 / (horizontal) 9600 x 1440 M: (vertical) 6400 x 2160 / (horizontal) 6400 x 1440 |
| Sensitivity |
Static image |
Standard Output: AUTO1 / AUTO2 / AUTO3 / ISO160 ~12800 (1/3 step) Extended Output : ISO80 / 100 / 125 / 25600 / 51200 |
| |
Filming |
Standard output sensitivity : AUTO / ISO160 ~12800 (1/3 step) Extended output sensitivity : ISO25600 |
| Exposure control |
TTL 256-zone metering, multiple / spot / average / center-weighted |
| Exposure mode |
P(program AE) / A(aperture priority AE) / S(shutter speed priority AE) / M(manual exposure) |
| Exposure compensation |
Still |
-5.0EV ~ +5.0EV step 1/3EV |
| |
Filming |
-2.0EV ~ +2.0EV in 1/3EV steps |
| Shutter Type |
Focal plane shutter |
| Shutter speed |
Mechanical shutter |
P mode: 4sec. 1/4000sec. A mode: 30sec. to 1/4000sec. S/M mode: 15min. to 1/4000sec. Bulb mode: up to 60min. |
| |
Electronic shutter |
P mode: 4sec. up to 1/32000sec. A mode: 30sec. up to 1/32000sec. S/M mode: 15min. to 1/32000sec. Bulb mode: 1sec. Fixed
*Electronic shutter may not be suitable for fast moving subjects or handheld shooting. Flash cannot be used. |
| |
Mechanical + electronic shutter |
P mode: 4 sec to 1/32000 sec. A mode: 30sec. 1/32000sec. S/M mode: 30 min: 15 min. to 1/32000sec. Bulb mode: up to 60min. |
| Continuous shooting |
Approx. 30 fps [electronic shutter only, 1.25x crop ] (JPEG: 29 fps Compressed RAW: 17 fps Lossless RAW: 17 fps Uncompressed RAW: 17 fps) |
| |
Approximately 20 frames per second [electronic shutter only, 1.25 x crop ] (JPEG: 79 frames Compressed RAW: 20 frames Lossless RAW: 17 frames Uncompressed RAW: 17 frames) |
| |
Approximately 10 frames per second [electronic shutter only, 1.25 x crop ] (JPEG: 153 frames Compressed RAW: 26 frames Lossless RAW¼ 18 frames Uncompressed RAW: 18 frames) |
| |
Approx. 20 fps [Electronic shutter only] (JPEG: 32 fps Compressed RAW: 17 fps Lossless RAW: 17 fps Uncompressed RAW: 17 fps) |
| |
Approximately 10 frames per second [Electronic shutter only] (JPEG: 81 frames Compressed RAW: 21 frames Lossless RAW: 18 frames Uncompressed RAW: 18 frames) |
| |
Approximately 8 fps (JPEG: 105 fps Compressed RAW: 23 fps Lossless RAW: 18 fps Uncompressed RAW: 18 fps) |
| |
Approximately 5 fps (JPEG: 458 fps Compressed RAW: 46 fps Lossless RAW: 24 fps Uncompressed RAW: 19 fps) |
| |
Approximately 4 frames per second (JPEG: infinite RAW compression: 107 frames Lossless RAW compression: 28 frames Uncompressed RAW: 20 frames) |
| |
Approximately 3 frames per second (JPEG: Infinite RAW compression: 480 frames Lossless RAW compression: 34 frames Uncompressed RAW: 21 frames) |
| |
Pre-shooting: Approximately 30 frames per second [Electronic shutter only, 1.25x crop ] (max. 10 frames at half-press, max. 15 frames at full-press, max. 25 frames total) |
| |
Pre-shot: Approximately 20 frames/s [electronic shutter only, 1.25 x crop ] (max. 10 frames at half-press, max. 10 frames at full-press, max. 48 frames at full-press, max. 58 frames total) |
| |
Preframe: Approx. 10 fps [Electronic shutter only, 1.25 x crop ] (max. 10 frames at half-press, max. 110 frames at full-press, max. 120 frames total) |
| |
* The number of recordable frames depends on the recording medium * Continuous shooting speed depends on the environment and the number of frames |
| Drive mode |
Bracketing AE |
2 frames 3 frames 5 frames 7 frames 9 frames *in 1/3EV increments, up to ±3EV increments |
| |
Bracketing for film simulation |
Option to select any 3 types of film simulation |
| |
Dynamic range bracketing |
100% 200% 400% |
| |
ISO sensitivity bracketing |
±1/3EV ±2/3EV ±1EV |
| |
White balance bracketing |
±1 ±2 ±3 |
| |
Focus Bracketing |
AUTO MANUAL |
| |
Multiple exposure |
Yes (max. 9 frames) Additive Average Brightness Dark |
| |
HDR mode |
AUTO 200% 400% 800% 800% + |
| |
Advanced filter |
Camera to play with Miniature Pop color High-key Low-key Dynamic tone Soft Focus Partial color (red/orange/yellow/green/blue/purple) |
| Focus |
Mode |
Single Auto Focus / Continuous Auto Focus / MF |
| |
Type |
Intelligent Hybrid AF (TTL contrast AF / TTL phase detection AF) |
| |
Low light performance |
Contrast: -4.0EV *XF50mmF1.0 attached Phase Detection: -7.0EV *XF50mmF1.0 attached |
| |
AF frame selection |
Single-point AF: 13x9 / 25x17 (AF frame size can be changed) Zone AF: 3x3 / 5x5 / 7x7 of 117 areas on 13x9 grid Wide Angle/Tracking AF: Yes (AF-S: Wide Angle / AF-C: Tracking) All: Yes |
| |
Face/Eye Detection |
Yes |
| Flash |
Built-in flash |
Manual pop-up flash (Super Intelligent Flash) Directional number: approx. 7 (ISO200Em) / approx. 5 (ISO100Em) Effective range (ISO1600) Sync. Mode: 1st aperture / 2nd aperture Flash mode: TTL (TTL AUTO / STANDARD / SLOW SYNCHRONIZATION ) / MANUAL / COMMANDER / OFF |
| |
Flash with socket |
Sync. Mode: 1st Aperture / 2nd Aperture / AUTO FP (HSS) Flash mode: TTL (TTL AUTO / STANDARD / SLOW SYNC. ) / MANUAL / MULTI *When EF-X500 / OFF setting |
| Hot shoe |
Yes (compatible with dedicated TTL flash) |
| Viewfinder |
0.39-inch OLED colour viewfinder Approximately 2.36 million dots Imaging area coverage vs. sensing area: Approximately 100% Approximately 17.5 mm (from the rear end of the camera eyepiece) Diopter adjustment: -4 ~ +2m-1 Magnification: 0.62x with 50mm lens (35mm equivalent) at infinity and diopter set to -1.0m-1 Angle of view: approximately 31° (horizontal angle of view: approximately 26° ) Built-in eye sensor |
| LCD monitor |
3.0" color LCD touch screen monitor with flip-up screen 3:2 aspect ratio Approximately 1.62 million dots |
| Touch screen mode |
Photography mode |
Shooting / Auto focus / Focus area / Off / Double tap setting (ON/OFF) / Touch function setting (ON/OFF) / EVF touch screen area setting |
| |
Playback mode |
Swipe / Zoom in / Zoom out / Double tap / Drag |
| Video Recording |
File format |
MOV: MPEG-4 AVC/H.264, linear PCM (stereo audio 24bit/48KHz sampling) MP4: MPEG-4 AVC/H.264, AAC |
| |
Movie compression |
Long GOP |
| |
File Size / Frame Rate / Recording Time |
[DCI4K(17:9) 4096 x 2160] 29.97p/25p/24p/23.98p 200Mbps/100Mbps up to approx. 30min
[4K(16:9) 3840 x 2160] 29.97p/25p/24p/23.98p 200Mbps/100Mbps up to approx. 30min
[Full HD(17:9) 2048 x 1080] 59.94p/50p/29.97p/25p/24p/23.98p 200Mbps/100Mbps up to approx. 30min.
[Full HD(16:9) 1920 x 1080] 59.94p/50p/29.97p/25p/24p/23.98p 200Mbps/100Mbps up to approx. 30min.
[Full HD(16:9) High Speed 1920 x 1080] 240p/200p/120p/100p 200Mbps(recording) 240p/200p up to approx. 3min 120p / 100p up to approx. 6min.
* For movie recording, use an SD memory card with speed class UHS 3 or higher. * Recording time may be reduced depending on temperature and/or shooting conditions |
| Film simulation mode |
18 modes (PROVIA/STANDARD, Velvia/VIVID, ASTIA/SOFT, CLASSIC CHROME, PRO Neg. Hi, PRO Neg. Std, CLASSIC Neg., ETERNA/CINEMA, ETERNA BLEACH BYPASS, ACROS, ACROS+Ye Filter, ACROS+R Filter, ACROS+G Filter, MONOCHROME, MONOCHROME+Ye Filter, MONOCHROME+R Filter, MONOCHROME+G Filter, SEPIA) |
| Monochromatic colour |
Yes |
| Grain effect |
Roughness |
STRONG, WEAK, OFF |
| |
Size |
LARGE, SMALL |
| Color chrome effect |
STRONG, WEAK, OFF |
| Colour chrome Blue |
STRONG, WEAK, OFF |
| Dynamic range adjustment |
Still |
AUTO / 100% / 200% / 400% ISO limitation DR100%: No limitation, DR200%: ISO320 or more, DR400%: ISO640 or more |
| |
Film |
100% / 200% / 400% ISO limitation DR100%: No limitation, DR200%: ISO320 or more, DR400%: ISO640 or more |
| White balance |
Auto: White Priority / Auto / Ambient Priority User: Custom1 - 3 Color Temperature Selection: 2500K~10000K Preset: Soft / Shade / Fluorescent-1 / Fluorescent-2 / Fluorescent-3 / Incandescent / Underwater |
| Brightness setting |
±5 steps |
| Self-timer |
10sec / 2sec. |
| Interval sensing with timer |
Yes (Settings : Interval, Frame rate, Start time, Interval exposure smoothing) |
| Wireless transmitter |
Standard: IEEE802.11b/g/n (standard wireless protocol) WEP/WPA/WPA2 mixed mode encryption Access Mode: Infrastructure |
| Bluetooth® |
Standard: Bluetooth Ver. 4.2 (Bluetooth low energy) Operating Frequency (Medium Frequency): 2402~2480MHz |
| Terminal |
Digital Interface: USB Type-C (USB3.2 Gen1x1) HDMI output: HDMI Micro connector (Type D) Other: ø2.5mm, stereo mini connector (for microphone and remote trigger) / Hot shoe |
| Power supply |
Lithium-ion battery NP-W126S (included) Battery life for shooting: Normal mode Approximately 390 shots *At XF35mmF1.4 R setting
Actual battery life for movie shooting: 4K Approx. 45 min. (29.97p) / Full HD Approx. 45 min. (59.94p) *Face detection is set to OFF
Continuous battery life for video capture: 4K Approx. 60 min. (29.97p) / Full HD Approx. 75 min. (59.94p) *Face detection is set to OFF *Approximate number of frames or video recording time that can be taken with a fully charged battery based on the CIPA standard. |
| Dimensions |
Width: 118.4 mm Height: 82.8 mm Depth (minimum depth): 46.8 mm (31.9 mm) |
| Weight |
including battery and SD memory card: Approximately 378 g (including memory card) without battery and SD memory card: Approximately 329 g |
| Operating environment |
Operating temperature: 0℃~+40℃ Operating Humidity: 10% - 80% (non-condensing) |
| Commissioning time |
Approximately 0.4 sec. |
| Dodávané příslušenství |
Li-ion battery NP-W126S / USB cable / shoulder strap / body cap |
