Sony VENICE (MPC-3610)

Name: Sony VENICE (MPC-3610)
Brand: SONY
SKU: VENICE
Availability: OutOfStock

SKU: VENICE

The Sony VENICE has a FULL-FRAME 36x24mm sensor that was created for the demands of high-end film/camera production. VENICE can shoot at resolutions up to 6048 x 4032. The camera can natively support Super35 24.9x18.7mm at 4096x3024 resolution (which is the equivalent of 4 perforation film stock) and Super35 24.9x14mm at 4K resolution after switching the recording…

More information

Call us for pricing information

Price history

Availability

on request

SKU:
VENICE

Price history

Top accessories for Sony VENICE (MPC-3610)

Metabones PL to Emount adapter T (Black Matt)

Arri PL Lens to Sony E-Mount camera/ camcorders. Aluminum Alloy and Brass Construction

409 €

14-30 days

Product description SPECIFICATIONS

Product description

SPECIFICATIONS

Model Name

Model Name	MPC-3610

General

Power Requirements	DC12V (11~17.0V) DC24V (22~32.0V)
Operating Temperature	0 ~ 40°C
Storage Temperature	-20°C?60°C
Mass	Approx. 3.9kg (8lb 10oz) (without lens, handle, VF attachment expansion bottom plate and accessories)
Dimensions	133 x 159 x 172 mm (without protrusion)

Camera

Imaging Device	Full-Frame CMOS
Imaging Device Pixel Count	24.7M (total), 24.4M (effective)
Imaging Device Size	36.2x24.1mm. 43.5mm (diagonal).
Built-In ND Filters	Clear, 0.3(1/2), 0.6(1/4), 0.9(1/8), 1.2(1/16), 1.5(1/32), 1.8(1/64), 2.1(1/128), 2.4(1/256)
ISO Sensitivity	ISO500
Lens Mount	PL Mount E-mount (lever lock type, without supplied PL lens mount adaptor)
Latitude	15+ Stop
Select FPS*	Imager mode 3.8K 16:9, 4K 17.9: 1-60FPS 4K 4:3: 1-48FPS 4K 6:5, 5.7K 16:9, 6K 17:9, 6K 1.85:1, 6K 2.39:1: 1-30FPS 6K 3:2: 1-24FPS
White Balance	2000~15000Kelvin and Green/Magenta adjust, AWB*
Gamma Curve	S-Log3

Recording

Recording Format (Video)	XAVC 4K Class480: 23.98p, 24p, 25p, 29.97p XAVC 4K Class300: 23.98p, 24p, 25p, 29.97p, 50p, 59.94p XAVC QFHD Class480: 23.98p, 25p, 29.97p XAVC QFHD Class300: 23.98p, 25p, 29.97p, 50p, 59.94p MPEG HD422(1920x1080): 23.98p, 24p, 25p, 29.97p, 50i, 59.94i HD ProRes 422HQ: 23.98p, 24p, 25p, 29.97p, 50p, 59.94p, 50i, 60i HD ProRes 422: 23.98p, 24p, 25p, 29.97p, 50p, 59.94p, 50i, 59.94i HD ProRes 422 Proxy*: 23.98p, 24p, 25p, 29.97p, 50p, 59.94p, 50i, 59.94i
Recording Format (RAW/X-OCN) *required AXS-R7	RAW SQ 4K 17:9 (4096 x 2160): 23.98p, 24p, 25p, 29.97p, 50p, 59.94p 3.8K 16:9 (3840 x 2160): 23.98p, 25p, 29.97p, 50p, 59.94p X-OCN ST/LT 6K 3:2(6048 x 4032): 23.98p, 24p, 6K 2.39:1 (6048 x 2530): 23.98p, 24p, 25p, 29.97p 6K 1.85:1 (6048 x 3270): 23.98p, 24p, 25p, 29.97p 6K 17:9 (6048 x 3190): 23.98p, 24p, 25p, 29.97p 5.7K 16:9 (5672 x 3190): 23.98p, 25p, 29.97p 4K 6:5(4096x3432):23.98p, 24p, 25p, 29.97p 4K 4:3(4096x3024) :23.98p, 24p, 25p, 29.97p 4K 17:9 (4096 x 2160): 23.98p, 24p, 25p, 29.97p, 50p, 59.94p 3.8K 16:9 (3840 x 2160): 23.98p, 24p, 25p, 29.97p, 50p, 59.94p
Recording Format (Audio)	LPCM 4ch , 24-bit 48-kHz

Inputs/Outputs

DC Input	XLR-type 4pin (male)
Battery DC Input	Square-shaped 5pin connector
DC Output	12V: Hirose 4pin x1 24V: Fischer 3pin x2
SDI Output	BNC×4, (12G, 3G, 1.5G-SDI)
HD MONI Output	BNCx1 (1.5G-SDI)
HDMI Output	Type A ×1
VF	LEMO 26pin
Audio Input	XLR-type 5pin (female) x1 (LINE/ AES/EBU / MIC / MIC+48V selectable)
Timecode Input	BNC x1
Genlock Input	BNC x1
AUX	LEMO 5pin (female) x1 (Timecode Output)
Remote*	8pin x1
Lens*	12pin x1
Lens Mount Hot Shoe	4pin x2, conforming to Cooke /i Intelligent Electronic Lens System
Network*	RJ-45 type x1, 10BASE-T, 100BASE-TX
USB*	USB host, type-A x1
Headphone Output	Stereo mini jack x1
Speaker Output	Monaural
Media type	ExpressCard/34 slot×2 SD card slot ×1

WE RECOMMEND

The Sony VENICE is a state-of-the-art full-frame digital cinema camera equipped with interchangeable PL and E-mount lens systems and a standardized V-mount power supply. To achieve maximum performance when shooting in 6K resolution, it is essential to use certified SxS media and high-quality power systems that meet the demanding requirements of this production camera.

Storage Media and Readers - High-speed SxS media are essential for reliable recording of high data rates in XAVC-Intra and ProRes modes.

Lenses and optical accessories - E-mount lenses and teleconverters fully cover the VENICE camera’s full-frame sensor.

Batteries and Power - High-capacity V-mount batteries ensure long battery life for demanding camera operation and connected accessories.

Battery plates and mounting - Plates and adapters for the V-mount system allow for flexible power attachment to camera rigs.

Audio and Monitoring - Professional headphones and wireless sets for high-quality audio monitoring and recording right in the field.

Parameters

Manufacturer:	SONY
Category:	Digital Cinema

Main parameters

Camera Sensor size	Full Frame
Resolution	4K (DCI)
Resolution	UHD
Resolution	Full HD
Type of bayonet	PL
Type of bayonet	E-mount
Output	HDMI
Output	SDI
Output	12G SDI
Output	3G SDI

Other parameters

Version	film
Record format	ProRes
Record format	XAVC-Intra
Record format	MPEG HD
FPS	4K 60fps
FPS	6K 60fps
FPS	5.7K 30fps
FPS	4K 120fps
FPS	UHD 30fps
FPS	4K 24fps
FPS	HD 60fps
FPS	4K 30fps
FPS	UHD 60fps
FPS	4K DCI 110fps
FPS	HD 50fps
FPS	4K DCI 50fps
FPS	UHD 50fps
FPS	UHD 25fps
Media type	SxS
Battery type	V-mount
Colour depth	8 bit
Colour depth	10 bit
Colour depth	16 bit
Other features	Timecode
