Sony HXR-NX100

  • Free transport
SKU: HXR-NX100/J
This product is no longer offered. Please select from the alternatives below.

Top accessories for Sony HXR-NX100

PremiumCord Ultra High Speed HDMI 2.1 cable 8K@60Hz, 4K@120Hz length 2m metallic gold plated connectors

  • 8K resolution
High-end ULTRA HDMI 2.1 interconnect cable for the highest resolution 8K@60Hz and
9.7 €
In stock 4 pcs

PremiumCord Ultra High Speed HDMI 2.1 cable 8K@60Hz, 4K@120Hz length 1.5m metallic gold plated connectors

  • 8K resolution
High-end ULTRA HDMI 2.1 interconnect cable for the highest resolution 8K@60Hz and
9.3 €
In stock > 5 pcs

PremiumCord Ultra High Speed HDMI 2.1 cable 8K@60Hz, 4K@120Hz length 3m metallic gold plated connectors

  • 8K resolution
High-end ULTRA HDMI 2.1 interconnect cable for the highest resolution 8K@60Hz and
12 €
In stock 5 pcs

PremiumCord Ultra High Speed HDMI 2.1 cable 8K@60Hz, 4K@120Hz length 0.5m metallic gold plated connectors

  • 8K resolution
High-end ULTRA HDMI 2.1 interconnect cable for the highest resolution 8K@60Hz and
9.1 €
In stock > 5 pcs

CONST C-F970

Jednokanálová nabíjačka CONST C-F970 je schopná nabíjať jednu NP-Fxxx batériu pre
17 €
In stock > 5 pcs

PremiumCord optical fiber High Speed with Ether. 4K@60Hz cable 25m, M/M, gold plated connectors

Optical HDMI 2.0 Ultra High Speed 4K@60Hz cable is used to connect two audio/video
58 €
In stock 2 pcs

camRade run&gun Bag Medium

The run&gun Bag Medium is especially designed for professional cameras up to
217 €
In stock 1 pcs

Sony ECM-MS2

  • -18 %
Promotion: -18%
Affordable compact stereo/mono microphone with XLR input (cables with two XLR connectors
292.52 €
355.74 €
To be sent 2 pcs

Sony ECM-VG1

The Sony ECM-VG1 is a shotgun electret condenser microphone with directional characteristics.
254 €
To be sent 2 pcs

CONST ST-LBPS900

ST-L900 series (900Lux/1m LED camera light)
150 €
To be sent 1 pcs

Show all accessories

Product description SPECIFICATIONS PACKAGE CONTENT

Product description

NXCAM camera series equipped with a 1.0 Exmor™ R CMOS sensor with a maximum zoom of 48x and three independent lens control rings, recording in XAVC S, AVCHD and DV formats

FEATURES

  • Large 1" sensor using Exmor R CMOS technology
  • High sensitivity and high resolution (1.67 feet brighter than a 1/2.88 sensor)
  • Sony G lens 12x optical zoom (29mm wide), 24x zoom using Clear Image Zoom, up to 48x zoom using Digital Extender
  • Three independent lens control rings (focus, zoom, iris)
  • ND filters (Clear, 1/4ND, 1/16ND and 1/64ND)
  • Two slots for recording, "SIMUL" or "RELAY" recording
  • Multi-Interface (MI) Shoe
  • Multi-format recording capability(AVCHD, DV, XAVC S 50Mbps)
  • OUTPUTS: BNC (composite), RCA (audio), Micro USB, Stereo Mini Jack, HDMI (Type A)
  • 99 camera profiles

PACKAGE CONTENT

  • 1x Sony HXR-NX100 camcorder
  • 1x sun visor
  • 1x NP-F770 7.2v, 4400mAh battery
  • 1x charger
  • 1x rubber eyelet
  • 1x sled cap
  • 1x USB cable
  • 1x IR remote control RMT-845
  • 1x CR2025 Lithium battery installed
  • 1x AC-L100 AC Adapter
  • 1x power cable

SPECIFICATIONS

Effective: Approximately 10.6 MPA, B, Auto selectable

Camera
Sensor 1.0-type / 13.2 mm x 8.8 mm back-illuminated Exmor R CMOS sensor
Pixel Count 16:9
Effective: Approximately 14.2 MP

4:3
Built-In ND Filters Clear, 1/4, 1/16, 1/64
Minimum Illumination 60i: 3 lux (1/60 Shutter Speed, iris/gain auto)
60i: 1.7 lux (1/30 Shutter Speed, iris/gain auto)
Shutter Speed 60i: 1/8 - 1/10,000
24p: 1/6 - 1/10,000
Slow & Quick Motion Function 1080i 60p: 1, 2, 4, 8, 15, 30, 60
White Balance Preset
Indoor: 3200K
Outdoor: 5600K±7 steps
Color temparature set range: 2300-15000K
Onepush
Gain -3, 0, 3, 6, 9, 12, 15, 18, 21, 24, 27, 30, 33 dB, AGC
Gamma Curve Selectable
Lens
Lens Mount Fixed
Zoom Ratio 12x (optical), servo
Focal Length 9.3 to 111.6 mm
35mm Equivalent Focal Length 29 to 348mm (16:9)
35.5 to 426mm (4:3)
Iris f/2.8 to f/4.5, auto/manual selectable
Focus AF/MF selectable
Image Stabilizer ON/OFF selectable, shift lens
Filter Diameter 62mm
Recording
Video Format XAVC S HD : MPEG4-AVC/H264 4:2:0 Long profile
AVCHD : MPEG-4 AVC/H.264 AVCHD 2.0 format compatible
DV
Audio Format XAVC S HD : Linear PCM 2ch, 24bit, 48kHz
AVCHD : Linear PCM 2ch, 16-bit, 48kHz / Dolby Digital 2ch, 16-bit, 48kHz
DV : Linear PCM 2ch, 16-bit, 48kHz
Resolutions & Frame Rates XAVC S (1920 x 1080)@59.94p, 29.97p, 23.98p (50 Mbps)
AVCHD (1920 x 1080)@59.94p, PS mode (28 Mbps)
AVCHD (1920 x 1080)@59.94i/29.97p/23.98p, FX mode (24 Mbps) FH mode (17 Mbps)
AVCHD (1440 x 1080)@59.94i, HQ mode (9 Mbps) LP mode (5 Mbps)
AVCHD (1280 x 720)@59.94p, FX mode (24 Mbps) FH mode (17 Mbps) HQ mode (9 Mbps)
DV (720 x 480)@59.94i (25 Mbps)
Recording/Playback Time XAVC S HD@LPCM 2ch 50 Mbps
Approx. 155 min with 64 GB memory card

AVCHD@LPCM 2ch PS Mode
Approx. 290 min with 64 GB memory card
Approx. 145 min with 32 GB memory card

AVCHD@LPCM 2ch FX Mode
Approx. 340 min with 64 GB memory card
Approx. 170 min with 32 GB memory card

AVCHD@LPCM 2ch FH Mode
Approx. 450 min with 64 GB memory card
Approx. 225 min with 32 GB memory card

DV
Approx. 280 min with 64 GB memory card
Approx. 140 min with 32 GB memory card
Monitoring
Viewfinder 0.24"-type / 0.6 cm (approx. 1.56 M dots)
LCD Monitor 3.5" / 8.8 cm (approx. 1.56 M dots)
Input/Output
HDMI Output 1 x Type A
Composite Output 1 x BNC, NTSC 1.0Vp-p, 75 ohms
Audio Input 2 x XLR (3-pin), line/mic/mic +48 V selectable
Audio Output RCA
Accessory Shoe 1 x Multi Interface Shoe
USB Multi/Micro jack
Headphone Output 1 x 3.5 mm stereo mini jack
Speaker Output Monaural
DC Input DC jack
Remote 1 x 2.5 mm stereo mini jack
General
Media Type 1 x SD/SDHC/SDXC & Memory Stick Duo
1 x SD/SDHC/SDXC
Built-In Microphone Omni-directional stereo electret condenser microphone
Power Requirements Battery pack: 7.2 VDC
AC Adapter: 8.4 VDC
Power Consumption Approx. 5.8 W (while recording with viewfinder and XAVC S HD 1080/60i or 50i at 50 Mbps)
Approx. 6.0 W (while recording with LCD and XAVC S HD 1080/60i or 50i at 50 Mbps)
Operating Temperature 32 to 104°F / 0 to 40°C
Storage Temperature -4 to 140°F / -20 to 60°C
Dimensions (W x H x D) Approx.: 6.7 x 7.4 x 14.6" / 171.3 x 187.8 x 371.2 mm (with the accessories, excluding the grip belt and including the projecting parts)
Weight 4.19 lb / 1.90 kg (body only)
4.63 lb / 2.10 kg (with Lens Hood, EVF Eyecup, and NP-F970 Battery)

WE RECOMMEND

The Sony HXR-NX100 is a professional NXCAM camcorder equipped with a 1-inch Exmor R CMOS sensor that requires specific accessories to maximize its potential. Key technical specifications include power supply via Sony NP-F series batteries, recording to SDXC cards (ideally Class U3 for XAVC S), a 62mm lens thread for filters, XLR inputs for audio, and the LANC control protocol.

Power and Batteries - The camera uses the Sony NP-F standard. High-capacity batteries and dual-slot chargers are essential for long shooting days.

Audio Accessories - The camera is equipped with two XLR inputs with phantom power for professional microphones.

Remote Control and Monitoring - The LANC protocol allows for zoom and focus control from the tripod handle, while the HDMI output enables connection to a monitor.

Tripods and transport - Given the weight and handycam-style design, tripods with a load capacity of up to 4-5 kg and padded bags are ideal.

Parameters

Parameters

Manufacturer: SONY
Category: Compact cameras

Main parameters

Camera Sensor size1"
ResolutionFull HD
ResolutionHDV (720p)
ResolutionSD PAL
Zoom12x
Type of bayonetintegrated lens
OutputHDMI
OutputAnalog

Other parameters

Versionhandycam
Record formatXAVC S
Record formatAVCHD
Record formatDV
FPSHD 60fps
FPSHD 50fps
FPSSD PAL 50i
FPSHDV 50/60fps
Lens lens aperture2.8f
Min. focal length9.3mm
Max. focal length111.6mm
Media typeSD card
Battery typeNP-F
Colour depth8 bit
Filter diameter62mm
Control protocolLANC
