AVMATRIX VC41 1080p 3G-SDI PCIe 4-Channel Capture Card

SKU: VC41

AVMATRIX VC41 is a four-channel internal PCIe card for capturing up to four professional 3G-SDI sources at once. Its PCIe 2.0 ×4 interface carries uncompressed YUY2 video at low latency, adds hardware deinterlacing and works with OBS on Windows and Linux.

More information

429 € with VAT 354.55 € without VAT
Add to Compare Price history
Availability
14-30 days
SKU:
VC41
Add to Compare Price history

Top accessories for AVMATRIX VC41 1080p 3G-SDI PCIe 4-Channel Capture Card

Infinitek L-2.5CHWS 5m FLEX 3G/HD-SDI cable BNC-BNC

Canare L-2.5CHWS je tenký "Low Loss" flexibilný a odolný 75 ohm 4,2 mm koaxiálny
22 €
In stock > 5 pcs

Infinitek L-2.5CHWS 3m FLEX 3G/HD-SDI cable BNC-BNC

Canare L-2.5CHWS je tenký "Low Loss" flexibilný a odolný 75 ohm 4,2 mm koaxiálny
18 €
In stock > 5 pcs
Product description SPECIFICATIONS PACKAGE CONTENT

Product description

AVMATRIX VC41 is a four-channel internal PCIe card for capturing up to four professional 3G-SDI sources at once. Its PCIe 2.0 ×4 interface carries uncompressed YUY2 video at low latency, adds hardware deinterlacing and works with OBS on Windows and Linux.

Four 3G-SDI inputs in one PCIe slot

AVMATRIX VC41 is a four-channel internal 3G-SDI capture card for simultaneous capture of multiple professional video sources. The PCIe 2.0 ×4 interface provides high bandwidth and ultra-low latency for live production, streaming, recording and conferencing.

AVMATRIX VC41
4× 3G-SDI1080p60 per channelPCIe 2.0 ×4Uncompressed YUY21080i deinterlacingWindows, Linux

Uncompressed, low-latency video

The card delivers uncompressed YUY2 video, preserving source quality without additional hardware compression. PCIe transfer bandwidth reaches up to 2.5 GB/s.

4× 3G-SDI input

Four 3G-SDI inputs of up to 1080p60 per channel capture multiple professional sources at the same time.

Cleaner image

Hardware 1080i deinterlacing and a 3D noise-reduction algorithm help keep the image clean.

Windows, Linux and popular apps

Support for Windows 7 and Ubuntu Linux 18.04 or later enables use with OBS, Microsoft Teams and other applications; video can be streamed to YouTube, Facebook or Twitch.

Continuous operation

The gold-plated PCIe connector provides stable contact and the card is designed for long-term continuous operation.

AVMATRIX VC41 – infographicAVMATRIX VC41 – infographicAVMATRIX VC41 – infographicAVMATRIX VC41 – infographicAVMATRIX VC41 – infographicAVMATRIX VC41 – infographic

More information

About the device

AVMATRIX VC41 is a four-channel internal 3G-SDI capture card for simultaneous capture of multiple professional video sources. The PCIe 2.0 ×4 interface provides high bandwidth and ultra-low latency for live production, streaming, recording and conferencing.

Uncompressed, low-latency video. The card delivers uncompressed YUY2 video, preserving source quality without additional hardware compression. PCIe transfer bandwidth reaches up to 2.5 GB/s.

Cleaner images and continuous operation. Hardware 1080i deinterlacing and a 3D noise-reduction algorithm help maintain a clean image. The gold-plated PCIe connector provides stable contact and the card is designed for long-term continuous operation.

Windows, Linux and popular applications. Support for Windows 7 and Ubuntu Linux 18.04 or later enables use with OBS, Microsoft Teams and other applications. Video can be streamed to platforms such as YouTube, Facebook or Twitch. Multi-input models also support horizontal and vertical production formats.

Key features

  • a four-channel internal 3G-SDI capture card for simultaneous capture of multiple professional video sources
  • 4× 3G-SDI inputs
  • maximum resolution 1080p60 per channel
  • PCIe 2.0 ×4, up to 2.5 GB/s
  • uncompressed YUY2 video
  • hardware 1080i deinterlacing
  • 3D noise reduction
  • Windows and Linux
  • designed for continuous operation

PACKAGE CONTENT

  • 1× AVMATRIX VC41 capture card
  • 1× user documentation

SPECIFICATIONS

  • Computer interface: PCIe 2.0 ×4
  • Video I/O: 4× 3G-SDI inputs
  • Maximum resolution: 1080p60 per channel
  • Output format: uncompressed YUY2
  • PCIe bandwidth: up to 2.5 GB/s
  • Processing: 1080i deinterlacing, 3D noise reduction
  • Operating systems: Windows 7 or later, Ubuntu Linux 18.04 or later
  • Compatible software: OBS, Teams and other video-capture applications
Parameters

Parameters

Manufacturer: AVMATRIX
Category: Capture cards internal

Main parameters

Maximum resolutionHD
InputsSDI
Interface typePCI Express 2.0 x4

Other parameters

OtherMultiple inputs
