SWIT TD-R210A | 500W Super High load 48V/24V Flexible Stand-mounted Adaptor for dual batterieS, Gol

The SWIT TD-R210A is a high-load dual Gold Mount battery adapter delivering regulated 24V (240W) or 48V (up to 500W) output for high-power cinema lights. Designed for stand mounting, it features Neutrik XLR connectors and provides a portable power solution for fixtures such as ARRI Orbiter and SkyPanel S60/S120.

The SWIT TD-R210A is a professional 500W high-load battery adapter engineered to power demanding 24V and 48V cinema lighting fixtures using just two Gold Mount batteries. Designed for flexibility and portability, it provides regulated high-voltage DC outputs while maintaining stable and reliable performance on set.

High-power cinema lights often require 24V or 48V input to achieve full brightness. The TD-R210A enables this by combining two compatible high-load batteries to deliver:

• 24V regulated output (4-pin XLR) – up to 240W

• 48V regulated output (3-pin XLR) – up to 500W

Optimized for ARRI High-Power Fixtures

The ARRI Orbiter and ARRI SkyPanel S60-C / ARRI SkyPanel S120-C require 48V DC input to reach 100% light output and can draw over 400W. When paired with dual-voltage batteries such as the SWIT PB-H260A, the TD-R210A delivers a stable 48V, 500W output, enabling full-performance lighting in mobile or remote environments.

Reliable & Secure Connectivity

The adapter utilizes Neutrik 3-pin and 4-pin XLR connectors to ensure safe, stable high-current transmission. Its design allows mounting onto 25–45mm light stands or C-stands, making it ideal for studio grids and location lighting setups.

Compact, portable, and engineered for high-output performance, the TD-R210A is a powerful battery-driven solution for professional broadcast and cinema productions.

Key Features

• Dual Gold Mount battery installation

• Regulated 24V (240W max) and 48V (500W max) outputs

• Designed for high-power cinema projectors and LED lights

• Compatible with ARRI Orbiter & SkyPanel S60/S120 (48V full output)

• Neutrik 3-pin & 4-pin XLR connectors

• Mounts to 25–45mm light stands / C-stands

• Portable high-voltage battery power solution
