SWIT PL-S300D | 300W Bi-color Hard-light Studio TLCI99 LED Panel Light, SWIT Free Design for Lighti

The SWIT PL-S300D is a 300W bi-color soft light LED studio panel delivering 10,000 lux at 1 meter with a wide 64° beam angle, designed for large-scale broadcast studios, film sets, and event stage lighting requiring smooth, even illumination.

The SWIT PL-S300D 300W Bi-color Studio SMD Panel LED Light is a high-performance soft lighting solution engineered for professional broadcast, film, and live event environments. Built with 1,200 ultra-bright, long-life SMD LEDs, the PL-S300D produces a powerful yet soft and evenly distributed light output, reaching 10,000 lux at 1 meter with a half-peak 64° wide beam angle, making it ideal for illuminating large areas with consistent coverage.

Featuring a 2×1-foot panel design, the PL-S300D offers continuously adjustable bi-color temperature from 2700K to 6500K, enabling seamless adaptation to various lighting conditions. The fixture delivers outstanding color accuracy with CRI 96, TLCI 99, and SSI (D55) 75, ensuring natural and accurate color reproduction for professional camera applications. Designed for noise-sensitive environments, the fanless cooling system provides silent operation, while professional control options include DMX512, multiple dimming curves, and an onboard LCD display for precise adjustment of color temperature and brightness.

Key Features

• 300W bi-color soft light LED studio panel

• 2×1' panel size for large-area illumination

• High output: 10,000 lux @ 1m

• Wide 64° half-peak beam angle for soft, even light

• 1,200 ultra-bright long-life SMD LEDs

• Bi-color range: 2700K–6500K continuously adjustable

• Excellent color accuracy: CRI 96, TLCI 99, SSI (D55) 75

• Fanless design for completely silent operation

• Multiple dimming curves: Linear, Log, Exponential, S-curve

• DMX512 control for color temperature and dimming

• LCD display for color and dimmer values

• PowerCON TRUE1 AC input and loop output

• 48V DC input via 3-pin XLR

• IP20 protection rating

• Suitable for broadcast studios, film sets, and event stages
