Neumann KH 150 W

The Neumann KH 150 W is a premium white-finish bi-amplified active studio monitor designed for professional recording, mixing, mastering, and immersive audio applications. Featuring a powerful 6.5-inch woofer, advanced DSP processing, linear phase response, and compatibility with Neumann's MA 1 Automatic Monitor Alignment system,…

More information

2 029 € with VAT 1 676.86 € without VAT
-+
Availability
on request
Product description SPECIFICATIONS PACKAGE CONTENT

Product description

The Neumann KH 150 W is a premium white-finish bi-amplified active studio monitor designed for professional recording, mixing, mastering, and immersive audio applications. Featuring a powerful 6.5-inch woofer, advanced DSP processing, linear phase response, and compatibility with Neumann's MA 1 Automatic Monitor Alignment system, it delivers exceptional accuracy, deep bass extension, and reference-quality monitoring performance.

The Neumann KH 150 W combines reference-class monitoring performance with a modern white finish, making it an ideal choice for professional studios, immersive audio environments, broadcast facilities, and high-end content creation spaces. Designed according to Neumann's philosophy of maximum accuracy, minimal distortion, and superior translation, the KH 150 W enables engineers, producers, and creators to make critical listening decisions with complete confidence.

At the heart of the KH 150 W is a powerful 6.5-inch woofer housed in a front-ported bass reflex enclosure, paired with a precision 1-inch tweeter. This advanced driver combination delivers an extended low-frequency response down to 39 Hz while maintaining remarkable clarity and detail throughout the entire frequency spectrum. The monitor is particularly well suited for bass-intensive music genres such as EDM, hip-hop, urban production, and film scoring, while remaining equally capable for classical music, broadcast, voice-over, and general studio work.

The KH 150 W features a sophisticated DSP engine that provides linear phase correction, optimized crossover management, and advanced system protection. Full compatibility with the Neumann MA 1 Automatic Monitor Alignment system enables automatic room calibration, allowing the monitor to adapt precisely to the acoustic characteristics of virtually any listening environment.

Powerful built-in amplification delivers 145 W to the woofer and 100 W to the tweeter, providing exceptional headroom and maximum output levels of up to 118.7 dB SPL while preserving transparency and low distortion. Extremely tight manufacturing tolerances of ±0.8 dB ensure precise stereo imaging and outstanding consistency between monitor pairs.

Connectivity includes a balanced analog XLR input and digital S/PDIF input via RCA. The KH 150 W can also be integrated with other Neumann KH Series monitors and subwoofers for surround sound and immersive audio configurations, making it a flexible solution for both stereo and multi-channel monitoring systems.

Key Features

  • Premium active studio monitor with white finish
  • Bi-amplified design for maximum performance and accuracy
  • 6.5-inch woofer with front bass reflex ports
  • 1-inch precision tweeter with protective grille
  • Deep bass extension down to 39 Hz
  • DSP-controlled crossover and system optimization
  • Linear phase correction technology
  • Compatible with Neumann MA 1 Automatic Monitor Alignment
  • Extremely accurate frequency response and imaging
  • Tight production tolerance of ±0.8 dB
  • High maximum SPL capability of 118.7 dB
  • Balanced analog XLR input
  • Digital S/PDIF input
  • Advanced protection and limiter systems
  • Suitable for stereo, surround, and immersive audio systems
  • Can be combined with other Neumann KH Series monitors and subwoofers

PACKAGE CONTENT

  • 1 × Neumann KH 150 W Active Studio Monitor
  • Power Cable
  • User Documentation

SPECIFICATIONS

Acoustic Performance

  • Frequency Response (±3 dB): 39 Hz – 20.4 kHz
  • Maximum SPL: 118.7 dB SPL (1 m, 3% THD)
  • Self-Generated Noise: < 20 dB(A) SPL
  • Acoustic Principle: Front-ported bass reflex enclosure
  • Crossover Frequency: 1.7 kHz
  • FIR Phase Correction: Linear phase (105 Hz – 16 kHz, ±45°)

Amplification

  • Woofer Amplifier Power: 145 W
  • Tweeter Amplifier Power: 100 W
  • Amplification Type: Bi-amplified active system

Drivers

  • Woofer: 165 mm (6.5") low-frequency driver with white protective grille
  • Tweeter: 25 mm (1") high-frequency driver with white protective grille

Connectivity

  • Analog Input: Balanced XLR
  • Input Impedance: 24 kΩ
  • Digital Input: RCA (75 Ω) S/PDIF
  • Optional Network Control: Supported in AES67 variants
  • Control: Local or Network

User Controls

  • Input Gain: 0 dB to -15 dB
  • Output Level: 94 / 100 / 108 / 114 dB SPL
  • Bass EQ: 0 / -2 / -4 / -6 dB
  • Low-Mid EQ: 0 / -2 / -4 / -6 dB
  • Treble EQ: +1 / 0 / -1 / -2 dB

Protection Systems

  • Independent soft clip limiters
  • Peak limiters
  • Thermal protection limiters
  • Woofer excursion limiter
  • Amplifier thermal protection

Physical Specifications

  • Dimensions (H × W × D): 345 × 225 × 273 mm
  • Dimensions (Imperial): 13.58 × 8.86 × 10.75 in
  • Weight: 8.0 kg (17.6 lbs)
  • Finish: White
