Lilliput TK2700/T

Name: Lilliput TK2700/T
Brand: Lilliput
SKU: TK2700/T
Price: 479 EUR
Availability: OutOfStock

SKU: TK2700/T

The Lilliput TK2700/T is a 27" Full HD industrial touch monitor with 1000 nits – the largest of the metal TK series. The UV-resistant, anti-glare, anti-fingerprint glass offers 7H hardness and IK07 impact resistance, the front meets IP65/NEMA 4, 10-point capacitive touch usable with gloves. HDMI, VGA and AV inputs, 12–24 V power.

More information

479 € with VAT 395.87 € without VAT

Price history

Availability

on request

SKU:
TK2700/T

Price history

Top accessories for Lilliput TK2700/T

PremiumCord USB-C to HDMI Cable, 1.8 m, 4K*2K@60Hz Resolution, Aluminum

SHOWROOM PRAHA

This cable enables high-quality video and audio conversion from USB-C to HDMI connector

13 €

In stock 3 pcs

Canare HDMI Cable 5 m

Canare HDMI cable, 5 m long, with gold-plated HDMI Type A connectors on both ends.

20 €

In stock 4 pcs

Canare HDMI Cable 3 m

Canare HDMI cable, 3 m long, with gold-plated HDMI Type A connectors on both ends.

14 €

In stock 4 pcs

PremiumCord Ultra High Speed HDMI 2.1 Optical Fiber Cable 8K@60Hz, Gold-Plated, 30 m

This HDMI 2.1 Ultra High Speed 8K@60Hz or 4K@120Hz optical cable is designed to connect

49 €

on request

Product description SPECIFICATIONS PACKAGE CONTENT

Product description

27 inches for public spaces and outdoors

A large Full HD screen with 1000 nits behind glass that resists UV, impacts and scratches. Build it into a kiosk or control cabinet, or mount it via VESA 100/200 mm.

27" 1920 × 10801000 nitsIP65 / NEMA 47H · IK07Glove touch

UV-resistant, anti-glare, anti-fingerprint glass

The UV-resistant treatment extends outdoor life, the anti-glare, anti-fingerprint glass reduces reflections and stays clean despite frequent touching. 7H hardness and the IK07 test protect against scratches and impacts.

−10 to 50 °C

Vibration 1.5 Grms and 10 G shock per IEC 60068.

2× USB-A

For touch control and firmware updates.

2 speakers

Plus a 3.5 mm headphone output.

12–24 V DC

Max. 41 W, 12 V / 5 A adapter included.

Rear with VESA

Electronics box with VESA 100/200 mm holes and connectors on the bottom edge.

Touch even with gloves

The sensitive capacitive layer reacts to wet fingers and to rubber, latex and PVC gloves.

More information

About the TK2700/T

The Lilliput TK2700/T is a 27" metal monitor – the largest in the metal-framed TK range – with a high-brightness 1000-nit panel and 10-point capacitive touch. Besides HDMI and VGA it has an RCA / composite input for legacy video. The panel is made specifically for this model with an anti-glare layer, an anti-fingerprint treatment that keeps it clean when touched, and UV resistance for clear outdoor viewing.

Touch connects to the computer over USB and behaves like a mouse. The unit has no processor of its own – it is purely a monitor – and pairs well with industrial PCs, Raspberry Pi or Kinco xF-SiHMI units (resolution exactly 1920 × 1080). With its IP65 front it works reliably from −10 to +50 °C and mounts via VESA or the supplied cabinet brackets.

PACKAGE CONTENT

Lilliput TK2700/T monitor
12 V / 5 A power adapter
HDMI A–A cable
VGA cable
USB-A to USB-C cable (for touch)
Video & audio cables
Mounting screw kit (14 pcs)
Cable clamps (4 pcs)

SPECIFICATIONS

Model: TK2700/T
Display: 27" LCD
Resolution: 1920 × 1080
Aspect ratio: 16:9
Brightness: 1000 cd/m²
Contrast: 1000:1
Viewing angle: 178° / 178° (H/V)
Screen coating: UV-resistant, anti-glare, anti-fingerprint
Hardness / impact: ≥ 7H (ASTM D3363) / ≥ IK07 (IEC 62262 / EN 62262)
Touch panel: 10-point capacitive
Inputs: 1× HDMI, 1× VGA, 1× audio & video (RCA), 2× USB-A (touch and upgrade)
HDMI formats: 2160p 24/25/30, 1080p 24/25/30/50/60, 1080i 50/60, 720p 50/60
VGA formats: 1080p 24/25/30/50/60, 1080psF 24/25/30, 1080i 50/60, 720p 50/60
Audio: 2× speaker, HDMI (2ch), 3.5 mm headphone output
Power input: DC 12–24 V
Power consumption: ≤ 41 W (12 V)
Protection rating: front panel IP65 (IEC 60529), NEMA 4
Vibration: 1.5 Grms, 5–500 Hz, 1 h/axis (IEC 60068-2-64)
Shock: 10 G, half-sine, 11 ms (IEC 60068-2-27)
Operating temperature: −10 to 50 °C
Storage temperature: −20 to 60 °C
Dimensions (W × H × D): 658.4 × 396.6 × 51.8 mm
Weight: 9.5 kg
Mounting: VESA 100/200 mm, panel mounting with screws
Housing: metal housing

WE RECOMMEND

Recommended for the Lilliput TK2700/T:

Cables – to connect the video source

Parameters

Manufacturer:	Lilliput
Category:	Studio Monitors

Main parameters

Supported video signal modes (resolution / frame rate)	1080i up to 60i · 720p up to 60p · 1080p up to 60p · 4K UHD up to 30p
Size	27"
Monitor inputs	HDMI · Composite Video · VGA
Luminosity	1000cd/m2
Panel resolution	1920x1080
Monitor power supply	DC 12–24 V
