Kinefinity MAVO Edge 8K
SKU: A010-001-01
The Kinefinity A010-001-01 MAVO Edge 8K is a groundbreaking carbon-fiber full-frame 8K cinema camera weighing just 1.5 kg, delivering internal ProRes 4444 XQ at 8K 75 fps open-gate or 70 fps 16:9, 2K 286 fps slow-motion, 14+ stops DR with dual-native ISO 800/5120, motorized e-ND (2–7 stops), 12 ms rolling shutter, dual NVMe KineMAG Nano SSDs, full…
Promotion: -17% ends in: 9d: 23h: 21m
14 519 €
12 098.79 € with VAT
9 999 € without VAT
Availability
on request
Top accessories for Kinefinity MAVO Edge 8K
Kinefinity MAVO mark2 LF (PL Mount)
The Kinefinity MAVO mark2 6K LF (A010-003-04) is a full-frame 6K cinema camera with
8 109 €
on request
Kinefinity Camera Core Pack
The Kinefinity Camera Core Pack (MAVO Edge Essential Accessory Pack) (A901-001-01)
4 969 €
on request
Kinefinity MAVO mark2 S35 (PL Mount)
The Kinefinity MAVO mark2 S35 (A010-004-04) is a Super35 cinema camera with 3:2 CMOS,
5 689 €
on request
Kinefinity KineMON Coldshoe Mount
The Kinefinity Cold Shoe Adapter Mount (A612-504-01) secures KineMON-5U/7H monitors
73 €
on request
Kinefinity Kine Video Cord (0.3M)
Promotion: -10% ends in: 9d: 23h: 39m
The Kinefinity Kine Video Cord (A612-001-01) is a 30 cm (12") right-angle 14-pin
129.47 €
144 €
on request
Product description
SPECIFICATIONS
PACKAGE CONTENT
Product description
The Kinefinity A010-001-01 MAVO Edge 8K is a groundbreaking carbon-fiber full-frame 8K cinema camera weighing just 1.5 kg, delivering internal ProRes 4444 XQ at 8K 75 fps open-gate or 70 fps 16:9, 2K 286 fps slow-motion, 14+ stops DR with dual-native ISO 800/5120, motorized e-ND (2–7 stops), 12 ms rolling shutter, dual NVMe KineMAG Nano SSDs, full XLR audio, and the revolutionary 12 mm KineMOUNT for instant EF/PL/LPL swapping—all in a Netflix-approved, future-proof hybrid beast.
The Kinefinity MAVO Edge 8K redefines high-end cinematography with a 44.7 MP full-frame sensor (8192×5456 open-gate) inside an ultra-light 1.5 kg carbon-fiber body, recording oversampled 8K ProRes 4444 XQ internally at up to 75 fps (3:2) or 70 fps (16:9), 6K 100 fps, 4K 150 fps, and insane 2K 286 fps slow-motion directly to dual KineMAG Nano NVMe SSDs. Its 14+ stops of dynamic range, dual-native ISO 800/5120, and KineLOG3 gamma rival ARRI Alexa while costing a fraction. A built-in motorized e-ND system (ND 0.6–2.1, 0.3-stop steps) lives inside the 12 mm KineMOUNT, enabling seamless exposure control without changing aperture or shutter angle. Full professional I/O includes dual XLR 48V phantom, dual 3G-SDI, Genlock/TC, Gigabit Ethernet, Wi-Fi 5, and RS-232 trigger. Power options span V-mount, BP-U, DC, and hot-swap NP-F baseplate. The MAVO Edge 8K delivers unmatched resolution, color science, and flexibility in a package that fits in a backpack.
Key features
- 44.7 MP full-frame 8K CMOS (8192×5456 open-gate)
- Internal ProRes 4444 XQ / 4444 / 422 HQ up to 8K 75 fps
- 8K 70 fps 16:9, 6K 100 fps, 4K 150 fps, 2K 286 fps
- Dual native ISO 800 & 5120 (14+ stops, KineLOG3)
- Motorized e-ND 0.6–2.1 (2–7 stops, 0.3-step precision)
- 12 ms rolling shutter (virtually zero skew)
- KineMOUNT 12 mm flange (tool-free EF3/PL/LPL/e-ND/KineEnhancer)
- Dual KineMAG Nano NVMe SSD slots (10 Gb/s USB-C offload)
- Dual XLR 48V phantom + 3.5 mm mic/headphone
- Dual 3G-SDI, TC/Genlock, Gigabit LAN, Wi-Fi 5, RS-232
- Carbon-fiber body (1.5 kg / 3.3 lb)
PACKAGE CONTENT
- Kinefinity MAVO Edge 8K Digital Cinema Camera
SPECIFICATIONS
- Model: Kinefinity A010-001-01 MAVO Edge 8K
- Sensor: 44.7 MP full-frame CMOS (36×24 mm)
- Active resolution: 8192×5456 (open-gate), 8192×4320 (8K 16:9)
- Max frame rates: 8K 75 fps (3:2) / 70 fps (16:9), 6K 100 fps, 4K 150 fps, 2K 286 fps
- Codecs: ProRes 4444 XQ (12-bit), 4444, 422 HQ, 422, 422 LT
- Bit depth: 10-bit / 12-bit (4444 XQ)
- Dynamic range: 14+ stops
- ISO: Dual native 800 & 5120 (250–25,600 expanded)
- e-ND: Motorized 0.6–2.1 (ND 4–128), 0.3-stop steps
- Shutter: Electronic rolling, 12 ms full read
- Mount: KineMOUNT (12 mm FFD)
- Media: 2× KineMAG Nano (1TB/2TB NVMe M.2)
- Audio: 2× XLR 48V, 24-bit 48 kHz LPCM
- Video out: 2× 3G-SDI (up to 1080p60 + metadata)
- Sync: TC in/out (LEMO), Genlock (BNC), RS-232, KineSYNC
- Power: V-mount / BP-U / DC 11–19 V / hot-swap NP-F
- Dimensions: 124 × 109 × 106 mm (body only)
- Weight: 1.5 kg / 3.3 lb (body only)
Parameters
Parameters
| Manufacturer: | Kinefinity |
| Category: | Compact cameras |
Main parameters
| Camera Sensor size | full-frame CMOS |
| Resolution | 44.7 MP (36×24 mm) |
| Type of bayonet | MAVO Edge |
| Output | 3G SDI |
Other parameters
| FPS | 8K 75 fps (3:2) / 70 fps (16:9), 6K 100 fps, 4K 150 fps, 2K 286 fps |
| Media type | KineMOUNT |
| Battery type | V-mount / BP-U / DC 11–19 V / hot-swap NP-F |
| Native ISO | 999999999.9 |
