Deity Adapter DXLR

The D-XLR converts 12-48V phantom power to 3V "Plug in Power", allowing microphones with 3.5mm TRS connectors to be operated via phantom power. The D-XLR is specifically designed for Deity's V-Series microphones to power their smart TRRS connectors from a standard XLR connector via PIP.

More information

29 € with VAT 23.97 € without VAT
-+
Personal pickup: 09. 12. from 09:00
Shipment day: 09. 12.
In stock 1 pcs
Praha 1 pcs
Product description ARTICLES

Product description

The D-XLR converts 12-48V phantom power to 3V "Plug in Power", allowing microphones with 3.5mm TRS connectors to be operated via phantom power. The D-XLR is specifically designed for Deity's V-Series microphones to power their smart TRRS connectors from a standard XLR connector via PIP.

Features:

  • Solid metal construction
  • sturdy belt clip
  • adapts 48V to 3V PIP (Plug in Power)
  • works with common 3.5mm microphones

D-XLR converts 12-48V phantom power to 3V "Plug in Power", allowing microphones with 3.5mm TRS connectors to operate via phantom power. The D-XLR is specifically designed for Deity V-Series microphones to power their smart TRRS connectors from a standard XLR connector via PIP.

At the same time, D-XLR has no negative impact on microphones like the V-Mic D3 Pro in terms of signal-to-noise ratio, absolute harmonic distortion and sensitivity. The D-XLR uses a standardized 3.5mm TRS* connector with a gold-plated surface, so the contacts on the connector stick better and don't loosen.

*It does not work with 3.5mm lavalier microphones wired for Sony UWP.

Compatible microphones:

  • A.Lav
  • V.Lav
  • V-Mic D3
  • V-Mic D3 Pro
  • other standard TS/TRS microphones

Technical specifications:

  • Weight: 29.2 g
  • Dimensions: 69.7 x 19 x 19 mm
  • Voltage: 12-48 V (phantom)
  • Bias voltage: 3V
  • Signal-to-noise ratio: 80.9 dB
  • THD: 0%
  • Input: 3.5mm standard TRS
  • Output: 3-pole XLR
  • Construction: CNC aluminum
