Blackmagic Design URSA Mini Pro Mount Screws PL

  • New
SKU: BMUMCAPRO/MSCRPL

Spare mounting screws for the PL mount of Blackmagic URSA Mini Pro cameras. The PL mount is held on the camera body by five M2.5 × 22 mm screws with a 2 mm hex socket, which are not used with any other mount. The URSA Mini Pro mount is interchangeable, so the screws are loosened often and easily lost.

More information

19 € with VAT 15.7 € without VAT
Add to Compare Price history
Personal pickup within 90 minutes
Shipment day: Today
In stock 2 pcs
Praha 2 pcs
SKU:
BMUMCAPRO/MSCRPL
Add to Compare Price history

Blackmagic Design URSA Mini Pro Mount Screws EF

In stock 2 pcs6.2 €without VAT 5.12 €
Product description SPECIFICATIONS PACKAGE CONTENT

Product description

Spare mounting screws for the PL mount of Blackmagic URSA Mini Pro cameras. The PL mount is held on the camera body by five M2.5 × 22 mm screws with a 2 mm hex socket, which are not used with any other mount. The URSA Mini Pro mount is interchangeable, so the screws are loosened often and easily lost.

PL mount screws for URSA Mini Pro

Original screws that hold the PL mount on the camera body.

5× M2.5 × 22 mm2 mm hex socketURSA Mini Pro

An interchangeable mount must never work loose

Lenses cost more than screws. A properly tightened mount holds the lens exactly on axis.

Screws by mount

The PL mount is held by five M2.5 × 22 mm screws with a 2 mm hex socket. These screws are exclusive to the PL mount and cannot be swapped with those of other mounts.

PL mount screws for URSA Mini Pro – Screws by mount

Changing the mount and tightening

The URSA Mini Pro mount can be changed between EF, PL, F and B4, and shims may be added under it to adjust the flange focal distance. Tighten the screws with a 2 mm hex key, ideally a torque wrench set to a maximum of 0.45 Nm, evenly and in the specified order. Some screws can only be reached after turning the PL locking ring. Overtightening can damage the thread and the mount.

PACKAGE CONTENT

  • Set of spare PL mount mounting screws for the Blackmagic URSA Mini Pro

SPECIFICATIONS

  • For use with: PL mount of Blackmagic URSA Mini Pro cameras
  • PL mount screws: 5× M2.5 × 22 mm, hex socket
  • Tools: 2 mm hex key, torque wrench recommended
  • Tightening torque: max. 0.45 Nm
  • Order number: BMUMCAPRO/MSCRPL
Parameters

Parameters

Manufacturer: Blackmagic Design
Category: Screws, screwdrivers
