Yamaha MGX16 Black

The Yamaha MGX16 is a full-featured digital mixing console designed for demanding live sound, studio, and streaming applications. Building on the trusted MG series legacy, the MGX16 delivers outstanding sound quality, expanded channel capacity, and powerful DSP tools in an intuitive and professional workflow.
With extensive routing options and multi-track recording, it is ideal for larger productions and installations.

Features

• 8 premium-quality Mic/Line combo inputs
• 8 mono channels, 4 stereo channels, and dedicated Sound Pad
• High-performance mic preamps with 86 dB gain range
• Ultra-low distortion and 125 dB dynamic range
• Creative DSP tools: Gate, Compressor, EQ, Reverb, Amp Simulator, Voice Changer
• 8 customizable sound pads with multi-bank assignment
• Touch LCD with advanced GUI, Touch & Turn knob, and customizable controls
• Scene Recall and Simple Mode for fast configuration switching
• Bluetooth audio input for wireless playback
• Dual MAIN / SUB USB ports for optimized integration
• Steinberg software suite included

Technical Specifications

• Inputs: 8 × Combo Mic/Line
• Channels: 8 mono, 4 stereo, 1 Sound Pad
• USB Recording / Playback: 18-track
• USB Ports: MAIN / SUB
• Outputs: 2 × XLR, 8 × TRS OMNI
• Headphone Outputs: 4
• Dimensions (W × H × D): 419 × 96 × 319 mm
• Weight: 4.7 kg
• Included Software: Steinberg Software Suite
