Teradek ACI Assistant Camera Interface No Radios

The Teradek RT ACI (Assistant Camera Interface) No Radios is a dedicated control module for RED DSMC2 cameras, providing tactile access to camera settings through 13 customizable menu buttons, a jog wheel, and an integrated LCD display. Designed for assistant camera operators, it simplifies adjustments such as start/stop, shutter speed, and color configuration while offering a lightweight, durable milled-aluminum chassis. The ACI requires a RED-approved DSMC2 Expander Module with CTRL (RS-232) port.

The Teradek RT ACI (Assistant Camera Interface) No Radios is a professional camera-control module designed to streamline operation of RED DSMC2 cameras on set. Instead of relying exclusively on touchscreen controls, the ACI provides dedicated tactile buttons and a jog wheel for fast, intuitive navigation through camera settings. Its redesigned menu interface provides convenient access to functions including camera start/stop, shutter speed, color configuration, and other RED camera controls.

The ACI features 13 menu function buttons and a jog wheel controller, with a fully customizable button layout that can be configured to suit individual workflows. An integrated LCD display provides clear menu navigation, while selectable UI themes and adjustable LED brightness make the interface suitable for both daylight and darker shooting environments.

Built around a lightweight yet durable milled-aluminum chassis, the ACI is designed for demanding production environments. The module connects to the assistant side of compatible DSMC2 cameras and uses the RED Command Protocol (RCP) for camera control. This No Radios version does not include integrated RF, FHSS, or Bluetooth functionality.

Important Compatibility Requirement: A RED-approved DSMC2 Expander Module with CTRL (RS-232) port is required for camera control.

Key Features

• Designed for RED DSMC2 cameras
• Assistant-side camera interface for professional production workflows
• Integrated LCD display with redesigned camera menu interface
• 13 dedicated menu function buttons
• Jog wheel for intuitive menu navigation
• Fully customizable button layout
• Provides access to start/stop, shutter speed, color configuration and other camera settings
• Adjustable LED brightness for daylight and interior/stage environments
• Two UI themes optimized for bright or dark shooting conditions
• Lightweight and durable milled-aluminum chassis
• Uses RED Command Protocol (RCP)
• No integrated radios
• No RF handset, FHSS, Bluetooth, or Teradek RT accessory support
• Firmware and configuration upgrades via Micro-USB
• Requires RED DSMC2 Expander Module with CTRL (RS-232) port
