SWIT KA-11B | B-mount single-sided battery plate, 28.8V

The SWIT KA-11B B-mount Battery Plate is a high-capacity 28.8V battery with 290Wh/10,005mAh designed to power B-mount cameras and professional video accessories. Featuring multiple outputs, an OLED status display, integrated flashlight, and rugged construction, it delivers reliable power for demanding field production.

The SWIT KA-11B B-mount Battery Plate provides dependable, high-capacity power for professional video workflows. With a 28.8V B-mount interface and 290Wh/10,005mAh capacity, it can continuously supply up to 10A to cameras, lights, and accessories. Its robust design includes multiple circuit protections against overcharging and short circuits, as well as an integrated OLED display to monitor battery status and remaining charge.

The battery offers versatile outputs including two 16V D-Tap ports, a 5V USB Type-A port, and a 60W USB Type-C input/output, making it ideal for powering a variety of devices and fast charging the battery itself. A built-in flashlight assists with mounting in low-light conditions, and the durable construction can withstand drops of up to 3.9 feet, ensuring reliability in the field. This B-mount single-sided battery plate combines performance, durability, and flexibility for professional on-set applications.

Key Features:

• High-capacity 290Wh / 10,005mAh B-mount battery

• Standard 28.8V B-mount interface for cameras and accessories

• Continuous 10A load, 100W/3A fast charging

• 2 x 16V D-Tap outputs, 5V USB Type-A, 60W USB Type-C input/output

• OLED status display for real-time monitoring

• Integrated flashlight for low-light mounting

• Built-in circuit protection against overcharge, short circuit, and overload

• Rugged design, drop-resistant up to 3.9 feet
