SMALLHD MON-CINE-24 Cine 24" 4K High-Bright Monitor

  • Free transport
SKU: MON-CINE-24

Cine 24 brings 4K, daylight-viewable monitoring everywhere. Lightweight for faster setup and teardown, this monitor is the all-around solution as a director’s monitor or for production and broadcast video villages. Cine 24 is SmallHD’s ultimate production workhorse.

More information

8 468.99 € with VAT 6 999.17 € without VAT
Add to Compare Price history
Availability
on request
SKU:
MON-CINE-24
Add to Compare Price history

Top accessories for SMALLHD MON-CINE-24 Cine 24" 4K High-Bright Monitor

Canare L-4.5CHWS Flexible 4K UHD, 12G-SDI Cable, BNC-BNC 10m

  • 4K / UHD
Canare L-4.5CHWS flexible and durable 75 ohm 4,2 mm "Low Loss" koaxial SD/HD/3G/12G-SDI
45.13 €
In stock > 5 pcs

HDMI cable 2.0 UHD 4K High Speed + Ethernet 10m

  • 4K / UHD
Propojovací HDMI 2,0 kabel UHD 4K High Speed + Ethernet kabel s integrovaným zes
45.92 €
In stock 2 pcs

SWIT S-8082S 95Wh V-Mount battery

Promotion ends in: 126d: 17h: 44m
S-8082S je 95Wh V-mount Li-ion batéria pre profesionálne video kamery.
200.28 €
To be sent 3 pcs

CONST Super 100Wh V-Mount battery LB-S100V

Characteristics: Const super LB-S100V battery can work together with another V-mount
274.39 €
on request
Product description SPECIFICATIONS PACKAGE CONTENT

Product description

Cine 24 brings 4K, daylight-viewable monitoring everywhere. Lightweight for faster setup and teardown, this monitor is the all-around solution as a director’s monitor or for production and broadcast video villages. Cine 24 is SmallHD’s ultimate production workhorse.

The Cine 24” 4K High-Bright Monitor offers 1350 nits of sustained brightness, enabling clear viewing in bright daylight environments, which eliminates the need for a sun hood or viewing tent. The 24-inch screen, the largest in our Cine series, features a 3840x2160 resolution as well as 10-bit color depth and 100% DCI-P3 color gamut for color-accurate images.

Cine 24 features four 12G SDI inputs and outputs as well as one HDMI 2.0 input. The Unibody Smart Chassis offers a Dovetail Mounting Rail for battery and accessory mounting, interchangeable mounting points, and 2x 2-pin accessory power outputs. Hot-swappable dual inputs allow you to add on Gold Mount or V-Mount battery plate attachments.

Meet Our Smart PageOS Software

With the power of SmallHD PageOS software, build customized Page Profiles, and utilize all of the dependable SmallHD features such as personalized frame guides, Focus & Exposure Assist, high-resolution 3D LUT overlays, histogram, vectorscope, waveform, and more.




PACKAGE CONTENT



SMALLHD MON-CINE-24 Cine 24" 4K High-Bright Monitor
SmallHD Cleaning Cloth
4K HDMI cable
Power Supply
Screen protector
Handle

SPECIFICATIONS



Environmental
Item Weight (oz) 16.5lbs/7.5kg
Height (in) 15.8 (w/out feet and handle) 17.8 (w/ feet and handle)
Width (in) 23.3 (w/out feet and handle) 23.6 (w/ feet and handle)
Length/Depth (in) 2.4 (w/out feet and handle) 4.7 (w/ feet and handle)

Display
Panel Type IPS LCD
Diagonal Size 24.1
Resolution 3840x2160
Brightness 1350nits
Contrast 1000:1
Gamut 100% DCI-P3
Color Depth 10-bit (8+2)
Viewing Angle 178 Degrees
Backlight Type Edgelit
Panel Resolution  3840 x 2160
Color Bit Depth 10-bit (8+2)
Input Signal
12G-SDI Input Types 4x 12G-SDI
HDMI Input Types 1x HDMI 2.0 (4K60)
Output Signal
12G-SDI Output Types 4x 12G-SDI
HDMI Output Types Coming Soon
Audio Output Types 1x 3.5mm 3-pin Stereo Headphone Jack
Data I/O Connector Type 1x SD Card Slot, 1x RJ45 Ethernet, 1x RJ45 GPI

Power Input 1x 3-pin XLR (210W max, 12V-34V, 18A max)
Output 2x 2pin (12V / 2A combined) 1x USB (2.4A) (Front) 1x USB (1.5A) (Front) 1x USB-C (5V / 1.5A)
Consumption 128w (monitor only) 209w (w/max access. power draw)
Battery Plate Included No
Battery Types 1x Dual-GM/VM Batt.Plate (14/26V) (sold as accessory)

Parameters

Parameters

Manufacturer: SmallHD
Category: Studio Monitors

Main parameters

Monitor inputsHDMI
Monitor inputsSDI
Monitor inputs4K HDMI
Monitor inputs12G SDI
Monitor power supplyV-Mount
Panel resolution3840x2160

Other parameters

Other featuresLightweight
