MagicSoft Streamer ver 2 with 3ch

MagicSoft Streamer Software Application for Live IP Streaming

More information

605 € with VAT 500 € without VAT
-+
Availability
1-2 days
Product description

Product description

MagicSoft Streamer Software Application for Live IP Streaming

MagicSoft Streamer is an application for live IP streaming designed for distribution and contribution that fulfills the demands of IP broadcasting.
The supported compressions are MPEG2 and H264 and the IP output can be UDP, RTP or RTMP (for Web distribution by using Wowza, YouTube, Twitch, etc).
We are also providing a receiver software that can decode and output UDP/RTP streams to a Decklink or Intensity card.

H264 UDP/RTP streams are compatible with the DVB IP infrastructure of multiplexers and decoders.

The conformance of the H264 UDP stream was tested with hardware measurement equipment such as Tektronix MTM 400 and Tandberg 7010 and software programs like Manzanita TSA, Elecard StreamEye, and ProMax TS Analyzer.


H264 UDP / RTP streams were tested and work 24 / 7 / 365 for devices like:
       - Tandberg TT1260
       - Tandberg RX1290
       - Ericsson RX8200
       - Amino A140

We are also providing a receiver software that can decode and output to a Decklink or Intensity card.

MagicSoft Streamer supports up to 4 video inputs using Decklink, Intensity, AJA, or Corvid cards and devices.
The input can be set as either analog or digital depending on the capabilities of the card ( so it can be SDI / HDMI / YUV or composite ).


Some of the RTMP servers that are supported :
YouTube, Twitch, Wowza, Vimeo, DaCast


There is a "Professional" module that adds some features :
       - stream recording that saves the stream as a .ts file simultaneous with sending it to the designated IP
       - YUV level legalizer (in order to ensure that the video level is kept within the appropriate range)
       - possibility to set the sampling rate as 4:2:2
       - possibility to work with a BlackMagic VideoHub device over the network for choosing the input

Parameters

Parameters

Manufacturer: MagicSoft
Category: Software
