EcoFlow RIVER 3 Plus

Like the other models in the RIVER 3 series, the RIVER 3 Plus battery station stands out for its compact size, fast charging speed, and quiet operation. It utilizes groundbreaking X-GaNPower technology, which minimizes heat loss and delivers high efficiency. In addition to these advantages, the RIVER 3 Plus offers significantly increased power output, a professional…

More information

304 € with VAT 251.24 € without VAT
-+
Availability
on request
Product description SPECIFICATIONS PACKAGE CONTENT

Product description

Like the other models in the RIVER 3 series, the RIVER 3 Plus battery station stands out for its compact size, fast charging speed, and quiet operation. It utilizes groundbreaking X-GaNPower technology, which minimizes heat loss and delivers high efficiency. In addition to these advantages, the RIVER 3 Plus offers significantly increased power output, a professional UPS with a switchover time of up to 10 ms, and the option to expand capacity with an additional battery. Recharging is possible via a wall outlet, car outlet, or solar panels.

Powering Appliances

With twice the power output of the RIVER 3 (up to 600 W), the RIVER 3 Plus can power even more energy-intensive appliances. The power output of the X-Boost function, suitable for powering heaters and certain types of motors, has also doubled compared to the RIVER 3, reaching up to 1,200 W.

Professional UPS for Uninterrupted Power Supply

The unit also offers a backup power supply function with truly professional specifications. Its automatic switchover time of 10 ms in the event of a power outage allows the unit to be used in a UPS system even for sensitive devices that require an uninterrupted power source.

Expandable station capacity

To extend the runtime of connected devices, you can connect an additional RIVER 3 Plus Smart Extra Battery EB300 (286Wh) or RIVER 3 Plus Smart Extra Battery EB600 (572Wh) to the station, expanding the total capacity up to 858 Wh.

Quiet operation

Thanks to X-GaNPower technology with improved heat dissipation, the station operates at a noise level of less than 30 dB at a distance of 45 cm, so its operation does not disturb your peace and quiet, day or night.

Phone control

Using the EcoFlow app, you can manage the RIVER 3 Plus from anywhere with an internet connection. The power station supports both Wi-Fi and Bluetooth, so it can easily adapt to current conditions.

PACKAGE CONTENT

General

Model:
EF-RV-H02-1

Weight:
Approximately 4.7 kg

Dimensions (W × D × H):
Approx. 234 × 232 × 146 mm

Output

AC waveform:
Pure sine wave

AC output (discharge only):
230 V ~ 50 Hz, 600 W max.

AC output (bypass mode):
220–240 V ~ 50/60 Hz, 600 W max.

USB-A output:
5 V ⎓ 2.4 A, 12 W max. per port, 24 W max.

USB-C output:
PD3.0, QC3.0, 5/9/12/15 V ⎓ 3 A max., 20 V ⎓ 5 A max., 100 W max.

DC output:
12.6 V ⎓ 10 A, 126 W max.

Input

AC input:
220–240 V ~ 50/60 Hz, 6 A max.

Solar input:
11-55 V ⎓ 13 A, 220 W max.

Car outlet input:
11-55 V ⎓ 8 A max., 220 W max.

Battery

Capacity:
286 Wh, 22.4 V ⎓ 12.8 Ah

Type:
LFP (LiFePO4)

Lifespan:
3,000 charge cycles until capacity drops to 80% (SoH) at 25 °C

Protection type:
Overvoltage protection, overload protection, overheating protection, short-circuit protection, low-temperature protection, undervoltage protection, overcurrent protection

Ambient temperature

Optimal operating temperature:
20 °C to 30 °C

Charging temperature:
0 °C to 45 °C

Discharge temperature:
–10 °C to 45 °C

Storage temperature:
–10 °C to 45 °C (optimally 20 °C to 30 °C)

Communication

Methods:
CAN, Wi-Fi, Bluetooth

Wi-Fi (2.4 GHz):
Frequency 2412–2472 MHz / 2422–2462 MHz, maximum output power 17.5 dBm

Bluetooth:
Frequency 2402–2480 MHz, maximum output power 9.50 dBm

Other

Operating altitude:
Up to 2,000 m above sea level

SPECIFICATIONS

1. RIVER 3 Plus
2. AC charging cable
4. USB-B to USB-A communication cable
5. User manual + warranty card

Parameters

Parameters

Manufacturer: EcoFlow
Category: Power supplies
