DJI Video Transmitter

The DJI Video Transmitter delivers high-definition 1080p60 video over long distances with ultra-low latency and AES 256-bit encryption. Designed for professional gimbals like the Ronin 2 and RS 3 Pro, it supports multiple receivers, HDMI/SDI inputs, and O3 Pro transmission technology for reliable, secure, and coordinated monitoring on large sets.

The DJI Video Transmitter is a professional wireless video transmission system built for high-end gimbals and filmmaking setups. Using DJI’s O3 Pro video transmission technology, it sends 1080p60 video up to 3.7 miles (6 km) line-of-sight to multiple receivers simultaneously. The system supports dual-band Wi-Fi (2.4 & 5.8 GHz), DFS frequencies, and 23 selectable channels for interference-free operation.

Equipped with HDMI 1.4 and 3G-SDI inputs, as well as a 3G-SDI loop output, the transmitter supports embedded audio at 16-bit/48 kHz. Transmission can be configured in Control mode (up to 2 receivers with remote control) or Broadcast mode (unlimited receivers at slightly reduced performance). AES 256-bit encryption ensures secure footage. The transmitter can be powered via L-series batteries, DJI gimbals, or DC input, making it a flexible and portable solution for large-scale productions.

Ideal for complex shooting scenarios, this transmitter is designed to work seamlessly with Ronin 2, RS 3 Pro, and compatible DJI cinema cameras, providing stable, low-latency video and reliable remote monitoring for professional crews.

Key Features:

• Transmits 1080p60 HD video over up to 3.7 miles (line-of-sight)
• DJI O3 Pro Video Transmission technology
• Supports simultaneous transmission to 2 receivers (Control mode) or unlimited receivers (Broadcast mode)
• HDMI 1.4 and 3G-SDI inputs; 3G-SDI loop output
• Embedded audio: 16-bit / 48 kHz PCM
• AES 256-bit encryption for secure video
• Dual-band Wi-Fi: 2.4 & 5.8 GHz with DFS support
• Auto frequency hopping or manual channel selection (23 channels, 40 MHz bandwidth)
• RF power: <33 dBm
• Low-latency: 68 ms
• Flexible power: L-series battery, DJI gimbal, or DC input
• Mounting options: cold shoe, 3/8"-16, 1/4"-20 threads
