DJI O3 Air Unit

The DJI O3 Air Unit brings immersive FPV performance to custom drones, delivering ultra-low-latency 1080p video transmission and onboard 4K recording. Powered by DJI O3+ technology, it offers long-range, stable video streaming to compatible DJI goggles with professional-grade image quality.

The DJI O3 Air Unit is a compact and lightweight FPV camera and video transmission system designed for drone builders seeking high-performance first-person flight. Using DJI’s advanced O3+ video transmission technology, it streams smooth 1080p H.265 video to compatible DJI Goggles from distances of up to 6.2 miles, providing an immersive and reliable FPV experience.

Equipped with a 1/1.7" image sensor and a super-wide 155° field of view, the O3 Air Unit captures stunning footage at up to 4K60 fps and stores recordings internally on its built-in 20GB memory. Ultra-low latency of just 30 ms ensures responsive control, while frequency auto-switching and 2T2R omnidirectional antennas maintain a stable signal even in challenging RF environments.

The system supports Canvas Mode for customizable on-screen displays and PID tuning, as well as D-Cinelike color mode for enhanced post-production flexibility. Compatible with DJI Goggles 2, FPV Goggles V2, and DJI FPV Remote Controller 2, the O3 Air Unit is an ideal solution for high-end FPV drone applications.

Key Features:

• Adds advanced FPV capabilities to custom-built drones
• DJI O3+ video transmission technology
• Streams 1080p H.265 video to compatible DJI goggles
• Ultra-long transmission range up to 6.2 miles (line-of-sight)
• Low-latency transmission down to 30 ms
• Records video internally up to 4K60 fps
• 20GB built-in storage for onboard recording
• 1/1.7" image sensor with 155° ultra-wide field of view
• Frequency auto-switching for stable signal performance
• 2T2R omnidirectional antenna system
• Canvas Mode support for customizable OSD and PID tuning
• D-Cinelike color mode for enhanced color grading flexibility
• Compatible with DJI Goggles 2, FPV Goggles V2, and FPV Remote Controller 2
