Hollyland Mars 400S Pro TX

This product is no longer offered. Please select from the alternatives below.
Product description

Product description

Mars 400S Pro TX, an updated version of Mars 400S, features a new design, better latency (0.08s); optional fan modes (Off, Low Speed & Auto); direct monitoring video feed for live streaming; optimized monitoring feed; data rate raised from 8 Mbps to 12 Mbps; multiple power options; and in-app channel scan as well as a firmware update.

The system supports 1x transmitter connection with up to 2 receivers; supports up to 2 mobile devices monitoring while only 1 receiver is connected; supports up to 4 mobile devices monitoring without a receiver connected. The modules feature OLED display screens; a channel scan feature, three application scene modes; a battery voltage display; 121 m transmission range (LOS); integrated cold shoes for quick installation; and versatile powering options.

Parameters:
Interfaces (Transmitter): HDMI Input (Type A Female), SDI Input, 2x Antenna Interface (RP-SMA Male), DC Input, USB Type-C
Power (each): Power Input: 6-16V=, USB Type-C 5V/2A, Battery: 6-16V=
Power Consumption: <11W (transmitter), <7W (Receiver)
Weight (each): 206 g
Dimensions (each, excl. battery plate): 110x72x33,5 mm
Input/Output Formats (Transmitter): HDMI: 480p60, 576p50, 720p50/59,94/60, 1080i50/59,94/60, 1080p23,98/24/25/29,9/30, 1080p50/59,94/60; SDI: 1080p60/59,94/50 (Level A), 1080p60/59,94/50 (Level B), 1080i60/59,94/50, 1080p30/29,97/25/24/23,98, 1080PsF 25, 720p60/59,94/50, 1080PsF 24/23,98
Frequency: 5 GHz
Modulation: OFDM
Transmission Power / Receiver Sensitivity: 21 dBm / 80 dBm
Latency: 0,08 s
Bandwidth: 20 MHz
Set Includes: 1x Transmitter

Parameters

Parameters

Manufacturer: Hollyland
Category: Wireless video transmission

Main parameters

Latency0,08s
Input wireless videoSDI
Input wireless videoHDMI
