Feelworld F7S (metal)

7" 4K camera monitor with IPS panel with 1920x1200 resolution, solid aluminium alloy body and 3G-SDI/HDMI inputs/outputs

• Display: 7" LED IPS
• Display resolution: 1920x1200
• Aspect ratio: 16:10
• Brightness: 450 cd/m²
• Inputs: 3G-SDI, HDMI
• Outputs: 3G-SDI, HDMI, headphone, integrated speaker
• Dimensions: 180x120x20.5 mm
• Weight: 445 g (without battery)

Whether you're shooting an independent film, a promotional video or footage from a cultural event, you need to make sure the video is perfectly sharp and properly exposed, whether you're using DSLR/DSLM cameras, digital film cameras or compact camcorders. With quality panel and focus assist features, as well as an unbeatable price, Feelworld monitors offer great value for money

True-to-life colour reproduction
Feelworld monitors support the Rec.709 standard, and are accurately factory calibrated for true colour reproduction. The IPS panel used (1200:1, 450 cd/m2, 323 ppi) offers a wide viewing angle of 160° for good colour reproduction from many directions



Connectivity
The F7S offers 3G-SDI and UHD/4K HDMI inputs/outputs, USB connector (for firmware updates), 3.5mm stereo headphone output and built-in speaker. The SDI interface supports standard SD and HD-SDI resolutions up to 1080p60, while the HDMI input supports UHD/4K resolutions up to 3840x2160p30 and 4096x2160p24 respectively



Compact, rugged design
The F7S monitor has a solid aluminum alloy body for high durability and light weight (20.5mm thick, 445g in weight). Easy operation is provided by buttons on the top edge of the display, including two F1/F2 function buttons that can be assigned any function, e.g. focus assist, false color display, etc. The bottom edge hosts a standard 1/4"-20 thread for mounting the monitor to DSLR/DSLM/camera rigs or directly to cameras using a flash socket reducer

Flexible power supply system
Feelworld monitors have a flexible power system: they come standard with an F970 battery plate, and can optionally be equipped with plates for D28S/D54, LP-E6, U60 batteries or an adapter for a mains power supply



Focus assist
Feelworld monitors offer a range of features for focus assist and correct exposure. The Focus Peaking indicator shows the in-focus parts of the image using red, green or blue tinting. The false-colour display then assists in correct exposure adjustment. The monitor also offers features for image zooming or inverting, histogram display, anamorphic mode or pixel-to-pixel mode
