Panasonic AK-UB300

This product is no longer offered. Please select from the alternatives below.
Product description

Product description

Panasonic's multi-purpose AK-UB300 camera is a 4K „box camera” equipped with a B4 mount, and is aimed at sports, remote studios, live concerts and aerial shooting. It provides 4K output (3G x 4) and simultaneous HD-SDI output. Available from November 2016.

Panasonic AK-UB300

Compact and lightweight, The AK-UB300 is equipped with a high resolution 4K image sensor which provides excellent image quality for sports broadcasts and other live events, and a B4 mount. Applying built-in conversion lens, 2/3” lens can be used with this 4K large-format camera without an adapter and achieve excellent image quality. The new imaging system makes maximum use of incident light to produce a wide dynamic range. With its compact size and excellent image quality, the camera is the perfect choice for monitoring and recording for various applications, such as aerial shooting from a helicopter, port monitoring, or recording road traffic information.

Simultaneous UHD/HD output allows you to decide whether to use 4K or HD video, according to your purpose. Users can also crop HD images from 4K images at any position. This cropping function called HD Cut-out Picture makes video suitable for many types of operations. Up to three cropping positions can be saved, allowing you to switch instantly by simply selecting one.

Panasonic AK-UB300

The AK-UB300 is also equipped with a variety of new functions for multi-purpose applications. Digital Haze Clear function ensures sufficient subject contrast and definition even under hazy conditions. Intelligent automatic adjust functions automatically correct picture level and color temperature as images are being recorded. When the camera’s flash causes light and dark areas to appear in the same frame, flash band compensation corrects it so the entire image is bright. The video output supports IP streaming with Full HD, and the operating workflow has been greatly innovated. Users can also build a system connecting the camera to Panasonic AW controller series, which offers the users not only excellent operating performance, but the ability to control the camera remotely via IP.

Panasonic AK-UB300

Parameters

Parameters

Manufacturer: Panasonic
Category: Broadcast

Main parameters

Camera Sensor sizeSuper35
Resolution4K (DCI)
ResolutionFull HD
Type of bayonetB4 2/3"
OutputSDI
OutputQuad SDI

Other parameters

Versionstudio
