DZO Pavo 2x anamorphic Prime 28mm T2.1-Neutral Coating- PL&EF mount (meter)

The DZO Pavo is a 28mm T2.1 2x anamorphic prime lens designed for professional filmmaking. Featuring a neutral coating for natural flares and colors, this compact lens delivers a classic cinematic look with its 2x squeeze factor. It is compatible with both PL and EF mounts.

More information

Promotion: -24% ends in: 42d: 10h: 37m
4 639 € 3 536.83 € with VAT 2 923 € without VAT
-+
Availability
on request
Product description SPECIFICATIONS

Product description

The DZO Pavo is a 28mm T2.1 2x anamorphic prime lens designed for professional filmmaking. Featuring a neutral coating for natural flares and colors, this compact lens delivers a classic cinematic look with its 2x squeeze factor. It is compatible with both PL and EF mounts.

The DZO Pavo 28mm T2.1 anamorphic prime lens is a compact and versatile tool for filmmakers seeking to achieve the classic widescreen, 2x anamorphic look. This lens features a neutral coating, which provides a natural, clean color rendition and helps to control flares. With a fast T2.1 maximum aperture, it offers excellent performance in low-light conditions and allows for a beautifully shallow depth of field. The 2x squeeze factor delivers a stunning anamorphic effect, while the 16-blade iris produces smooth, rounded bokeh. Its universal design includes a ø95mm front diameter and industry-standard 0.8 Mod gear pitch for seamless integration with wireless follow focus systems. The lens is compatible with both PL and EF mounts (interchangeable) and covers a Super35 image circle, making it a flexible option for a wide range of cinema cameras. At a lightweight 1203g, this lens is ideal for handheld operation, gimbals, and drones, while its close focus of 0.4m (1ft4in) allows for great detail on close subjects.

Key Features:

  • 2x anamorphic squeeze for a classic widescreen look
  • T2.1 maximum aperture for low-light performance
  • Neutral coating for natural colors and flares
  • PL & EF mount compatibility
  • 16-blade iris for smooth, circular bokeh
  • Standard 0.8 Mod gear pitch for focus and iris
  • Compact and lightweight design

SPECIFICATIONS

  • Focal Length: 28 mm
  • Colour: Space Grey + Black
  • Flare Option: Neutral
  • Mount: PL/EF
  • Aperture: T2.1-T22
  • Image Circle: ø31.5mm (S35)
  • Construction of Optics: 15 Elements in 13 Groups
  • Flange Distance: 52mm (PL) / 44mm (EF)
  • Close Focus: 0.4m / 1ft4in (from sensor plane)
  • Squeeze Factor: 2X
  • Iris Control: Manual (79°)
  • Focus Control: Manual (270°)
  • Front Diameter: ø95mm / 3.74"
  • Length: 106.3mm / 4.19"
  • Iris Blade: 16
  • Filter Size: M86
  • Gear Pitch: 0.8 Mod
  • Material: Aluminum Alloy
  • Weight: ≈1203g
Parameters

Parameters

Manufacturer: DZO Optics
Category: Lenses

Main parameters

BayonetPL
BayonetEF
