Aputure CF12 Compact Fresnel

The CF12 Compact Fresnel with Bowens bayonet features a 12-inch lens and offers a 15º-45º spot-flood range. It is optimized for use with STORM 1000c and 1200x headlamps. It is also compatible with the LS 1200d Pro, LS 600c Pro II and LS 600c Pro.

The CF12 Fresnel effectively increases the intensity of the STORM 1000c and 1200c lights by up to 9 times compared to their native output. The optics provide uniform light dispersion with a smooth gradient from center to edge, all in a compact and lightweight design achieved by a dual-expansion focusing system. This unique system allows the CF12 to increase the distance between the rear and front elements by extending both ends of the light tube, not just the front as with traditional fresnel fixtures.

The CF12 Fresnel can be paired with the separately available CF12 Barn Doors to give users even more control over the output of their STORM 1000c or 1200x. For easy transport, both the CF12 Fresnel and CF12 Barn Doors fit into the cases for the STORM 1000c and 1200x.

Features:

• 12-inch compact Bowens Mount Fresnel optimized for STORM 1000c and 1200x
• Spot-flood range from 15º to 45º
• Special focusing system significantly reduces the size and weight of the Fresnel
• Uniform light dispersion with a gentle drop towards the edges
• Increases the light intensity of the STORM 1000c/1200x up to 9 times

Technical Specifications:

• Beam Angle: Full Spot 15º, Full Flood 45º
• CF12 Fresnel dimensions: 38.3 x 37 x 12.8 cm
• Dimensions of the transport case: 49 x 22 x 45 cm
• CF12 Fresnel weight: 4.72 kg
• Weight of the transport case: 2.65 kg

Package contents:

• 1x CF12 Fresnel
• 1x shipping case
